Cooling water discharge hose with fibre glass cover
Highlights
It resists radiant heat up to +530°C
Length up to 120 m
Perfect vulcanization
Application
softwall hose for discharge of cooling water in steel mills, foundries, and in all cases where a rubber hose is working close to sources of heat. Resistant against splashes of white hot metal.
Temperature
from -40°C (-40°F) to +120°C (+248°F).
Construction
Tube: black, smooth, EPDM rubber.
Reinforcement: high strength synthetic cord.
Cover: covered with fibre glass, vulcanized, heat resistant. The fibre glass cover resists radiant heat up to +530°C (+986°F).
Reinforcement: high strength synthetic cord.
Cover: covered with fibre glass, vulcanized, heat resistant. The fibre glass cover resists radiant heat up to +530°C (+986°F).
Available upon request
1.Different diameters.
2.Different working pressures.
3.Essen/insulating with electrical resistance ≥1x108 Ω/m.
4. Essen/insulating/CR electrically isolating, with further CR rubber cover with fire resistant characteristics according to ASTM C 542.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Length max | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | m | ft | |
| 1345621 | 13 | 1/2 | 22 | 0,87 | 10 | 150 | 30 | 450 | 0,31 | 0,21 | 120 | 400 |
| 1308424 | 16 | 5/8 | 26,5 | 1,04 | 10 | 150 | 30 | 450 | 0,43 | 0,29 | 120 | 400 |
| 1244612 | 19 | 3/4 | 30,5 | 1,20 | 10 | 150 | 30 | 450 | 0,56 | 0,38 | 120 | 400 |
| 1297112 | 25 | 1 | 38,5 | 1,52 | 10 | 150 | 30 | 450 | 0,85 | 0,57 | 120 | 400 |
| 1308432 | 32 | 1-1/4 | 43 | 1,69 | 10 | 150 | 30 | 450 | 0,8 | 0,54 | 120 | 400 |
| 1297090 | 38 | 1-1/2 | 57,5 | 2,27 | 10 | 150 | 30 | 450 | 1,81 | 1,22 | 120 | 400 |
| 1368729 | 51 | 2 | 64,5 | 2,54 | 10 | 150 | 30 | 450 | 1,5 | 1,01 | 120 | 400 |
| 1308408 | 63,5 | 2-1/2 | 79 | 3,11 | 10 | 150 | 30 | 450 | 2,2 | 1,48 | 120 | 400 |
| 1348531 | 76 | 3 | 95,5 | 3,76 | 10 | 150 | 30 | 450 | 3,17 | 2,13 | 120 | 400 |
| 1314408 | 102 | 4 | 119,5 | 4,71 | 10 | 150 | 30 | 450 | 3,68 | 2,47 | 120 | 400 |
