Regulations
Abrasion loss of the tube according to ISO 4649: 70 +/- 5mm3.
/ Abr /
Orinoco
Sand blast hose
Highlights
Flexible for easy handling
High abrasion resistance
Conductive inner tube for operator safety
Application
abrasion resistant softwall hose, used for the delivery of sand or cast steel shot. It is manufactured with an antistatic rubber compound.
Temperature
from -40°C (-40°F) to +70°C (+158°F).
Construction
Tube: black, smooth, antistatic SBR/NR rubber, abrasion resistant.
Reinforcement: high strength synthetic cord.
Cover: black, smooth, (wrapped finish) antistatic SBR/NR rubber, abrasion resistant.
Reinforcement: high strength synthetic cord.
Cover: black, smooth, (wrapped finish) antistatic SBR/NR rubber, abrasion resistant.
Branding: continuous red stripe “IVG Abr (family logo)...”.
Available upon request
1.Different diameters
2.Different working pressures
3.Orinoco/2000 with abrasion loss of the tube 50+/- 5mm³ according to ISO 4649.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Length max | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | m | ft | |
| 1435612 | 13 | 1/2 | 25,5 | 1,00 | 10 | 150 | 30 | 450 | 0,39 | 0,27 | 120 | 400 |
| 1435620 | 16 | 5/8 | 29,5 | 1,18 | 10 | 150 | 30 | 450 | 0,52 | 0,35 | 120 | 400 |
| 1435531 | 19 | 3/4 | 32,5 | 1,30 | 10 | 150 | 30 | 450 | 0,58 | 0,40 | 120 | 400 |
| 1455729 | 25 | 1 | 40 | 1,58 | 10 | 150 | 30 | 450 | 0,8 | 0,54 | 120 | 400 |
| 1434560 | 30 | 1-3/16 | 45 | 1,77 | 10 | 150 | 30 | 450 | 0,93 | 0,63 | 120 | 400 |
| 1452983 | 32 | 1-1/4 | 48 | 1,89 | 10 | 150 | 30 | 450 | 1,1 | 0,74 | 120 | 400 |
| 1208705 | 38 | 1-1/2 | 52 | 2,05 | 10 | 150 | 30 | 450 | 1,07 | 0,71 | 120 | 400 |
| 1439421 | 40 | 1-37/64 | 60 | 2,36 | 10 | 150 | 30 | 450 | 1,65 | 1,14 | 120 | 400 |
| 1439430 | 51 | 2 | 69,5 | 2,76 | 10 | 150 | 30 | 450 | 1,86 | 1,30 | 120 | 400 |
| 1439545 | 60 | 2-3/8 | 80 | 3,15 | 10 | 150 | 30 | 450 | 2,31 | 1,61 | 120 | 400 |
| 1371290 | 63,5 | 2,1/2 | 83,5 | 3,29 | 10 | 150 | 30 | 450 | 2,48 | 1,67 | 120 | 400 |
| 1439740 | 65 | 2-9/16 | 83,5 | 3,31 | 10 | 150 | 30 | 450 | 2,3 | 1,60 | 120 | 400 |
| 1185128 | 80 | 3-5/32 | 103 | 4,06 | 10 | 150 | 30 | 450 | 3,55 | 2,38 | 120 | 400 |
| 1287494 | 102 | 4 | 122 | 4,81 | 10 | 150 | 30 | 450 | 3,65 | 2,45 | 120 | 400 |
