Avon
Anti-whip concrete placement
Highlights
Prevents whip effect
Designed for extreme operating conditions
High abrasion resistance allowing an extended service life
Application
concrete placement hose, with special textile plies used for concrete placement at casting locations; it is used as end hose in the concrete pump lines. The hose withstands suction under cleaning operations. Advantage: the hose absorbs shocks and vibrations and prevents the whip effect, making concrete pumping operations safer.
Temperature
from -40°C (-40°F) to + 70°C (+158°F).
Construction
Tube: black, smooth, hard NR/SBR rubber, that withstands the abrasion action of concrete.
Reinforcement: high strength special plies.
Cover: black, smooth (wrapped finish), hard NR/SBR rubber, abrasion and weathering resistant.
Reinforcement: high strength special plies.
Cover: black, smooth (wrapped finish), hard NR/SBR rubber, abrasion and weathering resistant.
Branding:
continuous orange type: "IVG Abr (application logotype)..."
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Vacuum | Length max | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | bar | m | ft | |
| 1456016 | 100 | 4 | 127 | 5,00 | 100 | 1500 | 200 | 3000 | 5,73 | 3,85 | 0,8 | 60 | 200 |
| 1464418 | 125 | 5 | 152 | 5,99 | 100 | 1500 | 200 | 3000 | 7,11 | 4,70 | 0,8 | 60 | 200 |
