Rail hose for compressed air AIR NF F 11-380/cat.2

Regulations

  • BS 6853
  • EN 45545
  • NF F11-380
BS 6853 Cat. Ia Int. Cat. Ia Ext.  EN 45545-2:2015 HL3 R22 and R23.  NF F11-380:2017/CAT.2.
Rail
/ Rail /

AIR NF F 11-380/cat.2

Compressed air hose

Highlights

Multiservice hose for compressed air
According to EN 45545-2 HL3 R22 and R23
Fire resistant, halogen free

Application

softwall hose designed to convey compressed air in rail carriages and locomotive systems according to the standard NF F11-380:2017/CAT.2. Fire resistant, with low toxicity and smoke emission. Halogen free.

Temperature

from -30°C (-22°F) to +70°C (+158°F).

Construction

Tube: black, smooth, synthetic rubber.
Reinforcement: high strength synthetic cord.
Cover: black, smooth (wrapped finish), synthetic rubber, weathering, ozone, oil and fire resistant.
Branding: continuous white band “IVG/quarter and year of production - I.D. - NF F 11 - 380 CAT 2 - batch n°”.

Available upon request

1.Different diameters.

Request information

I declare that I have read the privacy policy pursuant to EU Regulation 2016/679

Code Inside diameter Outside diameter Working pressure Burst pressure Weight nominal Length max
mm inch mm inch bar psi bar psi kg/m lbs/ft m ft
1450719 6 1/4 16 0,63 10 150 50 750 0,23 0,16 60 200
1438212 8 5/16 18 0,71 10 150 50 750 0,27 0,18 60 200
1438441 10 25/64 22 0,87 10 150 50 750 0,41 0,28 60 200
1432826 12 15/32 24 0,95 10 150 50 750 0,46 0,31 60 200
1449869 13 1/2 26 1,02 10 150 50 750 0,51 0,34 60 200
1414844 15 19/32 27 1,06 10 150 50 750 0,54 0,36 60 200
1438581 16 5/8 29 1,14 10 150 50 750 0,59 0,40 60 200
1436066 19 3/4 33 1,30 10 150 50 750 0,76 0,51 60 200
1432419 20 25/32 34 1,34 10 150 50 750 0,79 0,53 60 200
1432427 22 7/8 37 1,46 10 150 50 750 0,94 0,63 60 200
1449451 25 1 39,5 1,56 10 150 50 750 0,97 0,65 60 200
1437127 28 1/7-64 47 1,85 10 150 50 750 1,54 1,04 60 200
1480308 32 1 1/4 49 1,93 10 150 50 750 1,44 0,97 60 200
1499556 38 1 1/2 57 2,24 10 150 50 750 1,95 1,31 60 200
