Regulations
Abrasion loss of the tube according to ISO 4649: 40 +/- 5mm3.
/ Abr /
Orinoco HP
Sand blast hose
Highlights
Flexible for easy handling
Excellent abrasion resistance
Abrasion resistance ISO 4649: 40+/- 5mm³
Application
particularly abrasion resistant softwall hose, used for the delivery of highly abrasive media such as quartz sand, cast steel shot, corundum, glass. It is manufactured with antistatic rubber compound that prevents the risks of static electricity.
Temperature
from -40°C (-40°F) to +80°C (+176°F).
Construction
Tube: black, smooth, antistatic SBR/NR rubber, with special abrasion resistance that ensures a long service life.
Reinforcement: high strength synthetic cord.
Cover: black, smooth, (wrapped finish) antistatic synthetic rubber, abrasion resistant.
Reinforcement: high strength synthetic cord.
Cover: black, smooth, (wrapped finish) antistatic synthetic rubber, abrasion resistant.
Branding: continuous red stripe “IVG Abr (family logo)Orinoco HP...”.
Available upon request
1.Different diameters.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Length max | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | m | ft | |
| 1471007 | 13 | 1/2 | 27 | 1,06 | 12 | 180 | 42 | 630 | 0,48 | 0,33 | 120 | 400 |
| 1479091 | 16 | 5/8 | 30 | 1,18 | 12 | 180 | 42 | 630 | 0,56 | 0,38 | 120 | 400 |
| 1472208 | 19 | 3/4 | 33 | 1,30 | 12 | 180 | 42 | 630 | 0,64 | 0,43 | 120 | 400 |
| 1471589 | 25 | 1 | 39 | 1,54 | 12 | 180 | 42 | 630 | 0,78 | 0,52 | 120 | 400 |
| 1471570 | 32 | 1-1/4 | 50 | 1,97 | 12 | 180 | 42 | 630 | 1,32 | 0,88 | 120 | 400 |
| 1470191 | 32 | 1-1/4 | 48 | 1,89 | 12 | 180 | 42 | 630 | 1,11 | 0,75 | 120 | 400 |
| 1472283 | 38 | 1-1/2 | 56,5 | 2,23 | 12 | 180 | 42 | 630 | 1,49 | 1,01 | 120 | 400 |
| 1471627 | 42 | 1-24/32 | 60,5 | 2,38 | 12 | 180 | 42 | 630 | 1,61 | 1,08 | 120 | 400 |
| 1471341 | 60 | 2-3/8 | 80 | 3,15 | 12 | 180 | 42 | 630 | 2,37 | 1,59 | 120 | 400 |
