Sahara LL bd 240°C
Hot air blower hose from compressor to tank
Highlights
Suitable for all types of road tanker compressors
Extremely flexible
It resists the aggression of hot air
Application
hardwall hose designed for conveying hot, dry air from compressor to tank truck. Ideal for use where a particularly reduced bending radius is required.
Temperature
from -40°C to +200°C, peaks up to 240°C.
Construction
Tube: white, smooth, EPR rubber, heat resistant.
Reinforcement: high strength synthetic cord and steel helix wire.
Cover: blue, smooth (wrapped finish), EPDM rubber, weathering and ozone resistant.
Reinforcement: high strength synthetic cord and steel helix wire.
Cover: blue, smooth (wrapped finish), EPDM rubber, weathering and ozone resistant.
Branding: continuous white stripe “IVG Truck (Family logo)...”.
Available upon request
1.Different diameters
2. Sahara LL BD 180°C
3.Sahara LL 240°C (or 180°C) with black tube and cover
4.Sahara LL BD 240°C (or 180°C) with white rubber tube and black cover
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Bending radius | Vacuum | Length max | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | bar | m | ft | |
| 1419544 | 51 | 2 | 64 | 2,52 | 10 | 150 | 30 | 450 | 1,87 | 1,26 | 175 | 6,9 | 0,9 | 120 | 400 |
| 1418777 | 76 | 3 | 91 | 3,59 | 10 | 150 | 30 | 450 | 2,95 | 1,98 | 270 | 10,6 | 0,9 | 120 | 400 |
| 1418920 | 90 | 3-35/64 | 105,5 | 4,16 | 10 | 150 | 30 | 450 | 4,03 | 2,71 | 330 | 13,0 | 0,9 | 120 | 400 |
| 1419536 | 102 | 4 | 117,5 | 4,63 | 10 | 150 | 30 | 450 | 4,38 | 2,94 | 400 | 15,8 | 0,9 | 120 | 400 |
