Rail brake hose WS

Regulations

  • Specifica tecnica Trenitalia n° 373407
  • UNI CEI 11170
Technical Specification Trenitalia n° 373407 esp. 03.  UNI CEI 11170-1-2-3, LR4.
Rail
/ Rail /

WS

Rail brake hose

Highlights

Low toxicity and low smoke emission
Supplied in working lengths
Fittings available

Application

softwall hose designed as a flexible connection in air brake systems on rail carriages and locomotives. It is fire resistant with low toxicity and low smoke emission. Coils: supplied usually in application lengths with tapered ends.

Temperature

from -30°C (22°F) to +80°C (+176°F).

Construction

Tube: black, smooth, synthetic rubber.
Reinforcement: high strength synthetic cord.
Cover: black, smooth (wrapped finish), long lasting rubber, weathering, ozone, and oil resistant.
Branding: embossed stripe “IVG/class.../quarter and year of production” and coloured transfer stripe.

Available upon request

1.Different diameters.
2.Rail couplings.

Request information

I declare that I have read the privacy policy pursuant to EU Regulation 2016/679

Code Inside diameter Outside diameter Burst pressure Weight nominal
mm inch mm inch bar psi kg/m lbs/ft
1433016 8 5/16 18 0,71 75 1125 0,24 0,16
1389521 13 1/2 23,5 0,93 75 1125 0,35 0,23
1395033 16 5/8 26,5 1,04 75 1125 0,4 0,27
1389009 22 7/8 37 1,46 75 1125 0,8 0,54
1389017 28 1-7/64 45 1,77 75 1125 1,11 0,74
1389831 38 1-1/2 56 2,21 75 1125 1,51 1,00
