UIC Polar
Rail brake hose very low temperature, up to -50°C (-58°F)
Highlights
According to UIC-830-1
Length up to 120 m
Resistant up to -50°C
Application
softwall hose designed as a flexible connection in air brake systems on rail carriages and locomotives. Suitable for temperatures up to -50°C. Coils: supplied usually in application lengths with tapered ends.
Temperature
from -50°C (-58°F) to +70°C (+158°F).
Construction
Tube: black, smooth, synthetic rubber.
Reinforcement: high strength synthetic cord.
Cover: black, smooth (wrapped finish), synthetic rubber, flame proof , weathering and ozone resistant.
Reinforcement: high strength synthetic cord.
Cover: black, smooth (wrapped finish), synthetic rubber, flame proof , weathering and ozone resistant.
Branding: embossed label “IVG/year of production/batch/UIC-830-1”.
Available upon request
1.Different diameters.
2.Rail couplings.
| Code | Inside diameter | Outside diameter | Burst pressure | Weight nominal | Length max | |||||
|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | kg/m | lbs/ft | m | ft | |
| 1467654 | 8 | 5/16 | 23 | 0,91 | 70 | 1050 | 0,42 | 0,28 | 120 | 400 |
| 1467646 | 10 | 25/64 | 25 | 0,98 | 70 | 1050 | 0,47 | 0,32 | 120 | 400 |
| 1476130 | 13 | 1/2 | 28 | 1,10 | 70 | 1050 | 0,55 | 0,37 | 120 | 400 |
| 1468898 | 16 | 5/8 | 31 | 1,22 | 70 | 1050 | 0,63 | 0,42 | 120 | 400 |
| 1400043 | 18 | 23/32 | 33 | 1,30 | 70 | 1050 | 0,70 | 0,47 | 120 | 400 |
| 1467638 | 19 | 3/4 | 34 | 1,34 | 70 | 1050 | 0,71 | 0,48 | 120 | 400 |
| 1486667 | 22 | 55/64 | 40 | 1,57 | 70 | 1050 | 0,98 | 0,66 | 120 | 400 |
| 1468219 | 25 | 1 | 43 | 1,69 | 70 | 1050 | 1,07 | 0,73 | 120 | 400 |
| 1465554 | 28 | 1-7/64 | 46 | 1,81 | 70 | 1050 | 1,16 | 0,79 | 120 | 400 |
| 1400046 | 35 | 1-3/8 | 53 | 2,09 | 70 | 1050 | 1,40 | 0,94 | 120 | 400 |
