Rail brake hose UIC Cold

Regulations

  • DIN 5510
  • EN 15807
  • NF F 16-101
  • UIC-830-1-85
Cover according to DIN 5510-2 class S4 - SR2 - ST2 - FED<0,1.  EN 15807:2011.  NF F 16-101 F2 I2 (grid 5 and 6).  UIC-830-1-85.
Rail
/ Rail /

UIC Cold

Rail brake hose

Highlights

According to UIC-830-1 and EN 15807
Cover compound resistant to ozone and oil mist
Resistant up to -40°C

Application

softwall hose designed as a flexible connection in air brake systems on rail carriages and locomotives. Suitable for temperatures up to -40°C. Coils: supplied usually in application lengths with tapered ends.

Temperature

suitable for temperatures up to -40°C.

Construction

Tube: black, smooth, synthetic rubber.
Reinforcement: high strength synthetic cord.
Cover:

black, smooth (wrapped finish), synthetic rubber, weathering, ozone, and oil resistant (compound nr. 101486).


Branding: embossed label "IVG/year of production/batch/UIC-830-1".

Available upon request

1.Different diameters.
2.Rail couplings.

Request information

I declare that I have read the privacy policy pursuant to EU Regulation 2016/679

UIC_Cold_it.pdf
UIC_Cold_en.pdf
UIC_Cold_de.pdf
UIC_Cold_fr.pdf
UIC_Cold_ru.pdf
UIC_Cold_cn.pdf
See all documents
Code Inside diameter Outside diameter Burst pressure Weight nominal Length max
mm inch mm inch bar psi kg/m lbs/ft m ft
1469550 18 45/64 31 1,22 70 1050 0,61 0,41 60 200
1467441 22 7/8 39 1,54 70 1050 0,94 0,63 60 200
1457853 28 1-7/64 46 1,81 70 1050 1,21 0,81 60 200
1489917 35 1 3/8 54 2,13 70 1050 1,48 0,99 60 200
