Ammotech
Anhydrous ammonia hose
Highlights
Critical use
Safety factor 5:1
Safe and durable
Application
softwall hose for the delivery of liquid and gaseous anhydrous ammonia. It is particularly used in the processes of production of fertilizers. The operator must be instructed on use and maintenance of the hose for anhydrous ammonia. Failures in service may produce damage to people and property. Periodic inspections and tests allow detection of signals indicating the deterioration of the hoses or the loss of performance, before coming to malfunctions or failures.
Temperature
from -40°C (-40°F) up to + 55°C (+131°F).
Electrical Resistance
R≤1x106Ω/m.
Construction
Tube: black, smooth, antistatic synthetic rubber.
Reinforcement: high strength synthetic cord.
Cover: black, smooth (wrapped finish), antistatic synthetic rubber, resistant to chemicals, abrasion, ozone and weathering. Pin pricked cover.
Reinforcement: high strength synthetic cord.
Cover: black, smooth (wrapped finish), antistatic synthetic rubber, resistant to chemicals, abrasion, ozone and weathering. Pin pricked cover.
Branding: embossed marking: IVG CHEM AMMOTECH - ANHYDROUS AMMONIA - ISO 5771...
Available upon request
1. Different diameters.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Length max | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | m | ft | |
| 1470876 | 13 | 1/2 | 28 | 1,10 | 25 | 375 | 125 | 1875 | 0,53 | 0,36 | 120 | 400 |
| 1400385 | 16 | 5/8 | 31 | 1,22 | 25 | 375 | 125 | 1875 | 0,61 | 0,40 | 120 | 400 |
| 1470884 | 19 | 3/4 | 34 | 1,34 | 25 | 375 | 125 | 1875 | 0,69 | 0,47 | 120 | 400 |
| 1470892 | 25 | 1 | 42 | 1,65 | 25 | 375 | 125 | 1875 | 0,87 | 0,59 | 120 | 400 |
| 1473441 | 32 | 1-1/4 | 49 | 1,93 | 25 | 375 | 125 | 1875 | 1,11 | 0,75 | 120 | 400 |
| 1487671 | 38 | 1-1/2 | 58,5 | 2,30 | 25 | 375 | 125 | 1875 | 1,5 | 1,01 | 60 | 200 |
| 1486683 | 50 | 2 | 70,5 | 2,78 | 25 | 375 | 125 | 1875 | 1,87 | 1,26 | 60 | 200 |
