Regulations
VTT approuved Nordic Boat Standard MC9.
/ Boat /
Etna
Marine wet exhaust gas hose
Highlights
Approved by VTT and Lloyd's
Wide range of diameters
Excellent bending radius
Application
hardwall corrugated hose, flexible and lightweight, used to convey wet gas exhaust mixed with sea water in pleasure boats.
Temperature
from -30°C (-22°F) to +100°C (+212°F).
Construction
Tube: black, smooth, synthetic rubber, gas exhaust resistant
Reinforcement: high strength synthetic cord plus steel helix wire.
Cover: black, corrugated (wrapped finish), flame retardant synthetic rubber, weathering resistant.
Reinforcement: high strength synthetic cord plus steel helix wire.
Cover: black, corrugated (wrapped finish), flame retardant synthetic rubber, weathering resistant.
Branding:
continuous white/blue stripe “Boat (family logo) ETNA - MARINE WET GAS EXHAUST - LLOYD’S N° LR24147261TA - FIRE RESISTANT - ACCORDING MK9 VTT REP 761/97 (IVG LOGO)”.
| Code | Inside diameter | Burst pressure | Weight nominal | Bending radius | Length max | |||||
|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | bar | psi | kg/m | lbs/ft | mm | inch | m | ft | |
| 1386530 | 25 | 1 | 2 | 30 | 0,53 | 0,35 | 100 | 3,9 | 60 | 200 |
| 1391526 | 32 | 1-1/4 | 2 | 30 | 0,65 | 0,43 | 130 | 5,1 | 60 | 200 |
| 1390902 | 38 | 1-1/2 | 2 | 30 | 0,74 | 0,50 | 150 | 5,9 | 60 | 200 |
| 1383620 | 40 | 1-37/64 | 2 | 30 | 0,77 | 0,52 | 160 | 6,3 | 60 | 200 |
| 1383639 | 45 | 1-49/64 | 2 | 30 | 0,86 | 0,57 | 170 | 6,7 | 60 | 200 |
| 1378392 | 51 | 2 | 2 | 30 | 1,06 | 0,71 | 180 | 7,1 | 60 | 200 |
| 1383612 | 58 | 2-9/32 | 2 | 30 | 1,2 | 0,80 | 190 | 7,5 | 60 | 200 |
| 1383590 | 63,5 | 2-1/2 | 2 | 30 | 1,3 | 0,87 | 200 | 7,9 | 60 | 200 |
| 1383604 | 76 | 3 | 2 | 30 | 1,46 | 0,98 | 250 | 9,9 | 60 | 200 |
| 1384856 | 90 | 3-35/64 | 2 | 30 | 1,71 | 1,15 | 330 | 13,0 | 60 | 200 |
| 1384864 | 102 | 4 | 2 | 30 | 2,05 | 1,38 | 410 | 16,2 | 60 | 200 |
| 1385429 | 127 | 5 | 2 | 30 | 2,58 | 1,73 | 560 | 22,1 | 60 | 200 |
| 1393952 | 152 | 6 | 2 | 30 | 3,18 | 2,14 | 680 | 26,8 | 60 | 200 |
| 1396757 | 203 | 8 | 2 | 30 | 5,5 | 3,69 | 995 | 39,2 | 60 | 200 |
