Ace red ISO 3821
Extruded welding hose
Highlights
Weathering and ageing resistant
Lightweight and easy to handle
Extruded hose
Application
softwall hose suitable to convey acetylene and other combustible gases (except LPG, MPS, natural gas, methane) for welding.
Temperature
from -40°C (-40°F) to +60°C (+140°F).
Construction
Tube: black, seamless, synthetic rubber compound.
Reinforcement: high strength synthetic fabrics.
Cover: red, seamless, synthetic rubber compound, resistant to ozone, ageing and weathering.
Reinforcement: high strength synthetic fabrics.
Cover: red, seamless, synthetic rubber compound, resistant to ozone, ageing and weathering.
Branding: ISO 3821 2 MPa (20 bar) - IDxOD - IVG - PRUDUCTION YEAR - BATCH NUMBER.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Bending radius | Length max | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | m | ft | |
| 1467263 | 6,3 | 1/4 | 13,3 | 0,52 | 20 | 300 | 60 | 900 | 0,14 | 0,09 | 60 | 2,4 | 100 | 328 |
| 1467271 | 8 | 5/16 | 15 | 0,59 | 20 | 300 | 60 | 900 | 0,16 | 0,11 | 65 | 2,6 | 100 | 328 |
| 1467280 | 10 | 25/64 | 17 | 0,67 | 20 | 300 | 60 | 900 | 0,19 | 0,13 | 80 | 3,2 | 100 | 328 |
