Victoria LL
Steam hose for 210°C
Highlights
For steam up to +210°C
Reduced bending radius
Steel cord hose
Application
hardwall hose with steel cord reinforcement for saturated steam at a maximum working pressure 18 bar, used in the chemical industry, petrochemical and industrial applications in general, where a particular bending radius is necessary. Not recommended for steam cleaner. The hose can be used for peaks of superheated steam at 230°C and at 18 bar. Attention: the use of superheated steam reduces the hose life. For longer life drain after use.
Temperature
from -40°C (-40°F) to +210°C (+410°F).
Construction
Tube: black, smooth, EPDM rubber, resistant to saturated steam.
Reinforcement: inserts of steel wire and helix wire.
Cover: black, pin pricked, smooth (wrapped finish), EPDM rubber with excellent resistance to high temperatures, weathering, abrasion, and ageing.
Reinforcement: inserts of steel wire and helix wire.
Cover: black, pin pricked, smooth (wrapped finish), EPDM rubber with excellent resistance to high temperatures, weathering, abrasion, and ageing.
Branding: continuous embossed marking “IVG Steam Victoria/LL...”.
Available upon request
1.Different diameters.
2.Red cover.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Bending radius | Length max | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | m | ft | |
| 1256327 | 13 | 1/2 | 27,5 | 1,08 | 18 | 270 | 180 | 2700 | 0,68 | 0,50 | 84 | 3,3 | 60 | 200 |
| 1256343 | 19 | 3/4 | 33,5 | 1,32 | 18 | 270 | 180 | 2700 | 0,87 | 0,63 | 123 | 4,8 | 60 | 200 |
| 1231405 | 25 | 1 | 39,5 | 1,56 | 18 | 270 | 180 | 2700 | 1,15 | 0,84 | 162 | 6,4 | 60 | 200 |
| 1231430 | 32 | 1-1/4 | 48 | 1,89 | 18 | 270 | 180 | 2700 | 1,51 | 1,09 | 208 | 8,2 | 60 | 200 |
| 1231456 | 38 | 1-1/2 | 56 | 2,21 | 18 | 270 | 180 | 2700 | 2,06 | 1,46 | 247 | 9,7 | 60 | 200 |
| 1232541 | 51 | 2 | 69 | 2,72 | 18 | 270 | 180 | 2700 | 2,86 | 2,04 | 357 | 14,1 | 60 | 200 |
| 1265083 | 63,5 | 2-1/2 | 85,5 | 3,37 | 18 | 270 | 180 | 2700 | 4,43 | 3,10 | 444 | 17,5 | 60 | 200 |
| 1265180 | 76 | 3 | 98 | 3,86 | 18 | 270 | 180 | 2700 | 5,27 | 3,68 | 570 | 22,5 | 60 | 200 |
