Hawk
Pneumatic brake connection EN 45545 HL2, temperature down to -40°C (-40°F). Halogen free.
Highlights
Flexible
According to EN 45545-2 HL2 R22 and R23
Fire resistant, halogen free
Application
robust flexible hose for compressed air, designed for pneumatic braking systems in rail carriages and locomotives. Fire resistant, with really low toxicity and smoke emission, halogen free, it resists to ballast projections. Supplied in application lengths with tapered ends.
Temperature
-40°C (-40°F) up to +90°C (+194°F).
Construction
Tube: black, smooth, synthetic rubber.
Reinforcement: high strength synthetic cord.
Cover: black, smooth (wrapped finish), long lasting rubber, weathering and ozone resistant.
Reinforcement: high strength synthetic cord.
Cover: black, smooth (wrapped finish), long lasting rubber, weathering and ozone resistant.
Branding: embossed and/or coloured marking according to technical specification.
Available upon request
1.Different diameters.
2.With rail couplings.
3.According to specific technical standards (UIC 830-I, EN 15807, NF 11380, etc.).
| Code | Inside diameter | Outside diameter | Burst pressure | Weight nominal | Bending radius | Length max | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | kg/m | lbs/ft | mm | inch | m | ft | |
| 1478117 | 28 | 1-7/64 | 44 | 1,73 | 70 | 1050 | 1,11 | 0,75 | 280 | 11,0 | 60 | 200 |
