Rotterdam - Onshore

Regulations

  • EN 1765
  • RINA rules

EN 1765:2016 type S 15 DNV Type Approval TAP00002BW.



RINA approved n. MAC267219CS.


Onshore
/ Onshore /

Rotterdam

Dock oil hose according to EN 1765

Highlights

The best onshore quality
Each hose is tested
Supplied with fittings

Application

hardwall hose used for the suction and discharge of petroleum products from tankers and barges, bunkering service and industrial applications; suitable for aromatic content up to 50%. Realized with built-in fittings. Available also with swaged-on fittings up to internal diameter 152 mm (6"). Not suitable for SubMarine – Offshore Moorings applications.

Temperature

from -20°C (-4°F) to +82°C (+180°F).

Electrical Resistance

grade M.

Construction

Tube: black, smooth, synthetic rubber, suitable for aromatic content up to 50%.
Reinforcement: high strength synthetic cord, steel helix wire and copper wires.
Cover: black, smooth (wrapped finish), synthetic rubber resistant to weathering, oil and sea water.
Branding: continuous yellow stripe “On Shore Rotterdam Electrically Continuous EN 1765:2016 S15...” and marking according to specifications.
Request information

I declare that I have read the privacy policy pursuant to EU Regulation 2016/679

Code Inside diameter Outside diameter Working pressure Burst pressure Weight nominal Bending radius Vacuum Length max
mm inch mm inch bar psi bar psi kg/m lbs/ft mm inch bar m ft
1490958 51 2 72 2,84 15 225 60 900 2,8 1,89 300 11,8 0,9 12 40
1900752 76 3 97 3,82 15 225 60 900 4,15 2,78 420 16,5 0,9 12 40
1490966 102 4 134,5 5,30 15 225 60 900 8,23 5,53 560 22,1 0,9 12 40
1900756 152 6 190 7,49 15 225 60 900 16,75 11,24 850 33,5 0,9 12 40
1489259 203 8 245 9,65 15 225 60 900 25,33 16,55 1100 43,3 0,9 12 40
1800738 254 10 290 11,43 15 225 60 900 30,09 20,20 1350 53,2 0,9 12 40
1491016 305 12 350 13,79 15 225 60 900 39,64 26,66 1600 63,0 0,9 12 40
