Regulations
RINA approuved n. MAC258219CS.
EN 1765:2004 type S 15
/ Onshore /
Filicudi
Ship to ship petroleum products loading and unloading hose according to EN 1765 and BS 1435
Highlights
Ship-to-ship operations
Supplied with fittings
Robust construction
Application
hardwall hose used for the suction and discharge of petroleum products with an aromatic content up to 50% in ship to ship loading and unloading operations. Realized with built-in fittings. Available also with swaged-on fittings. Not suitable for SubMarine – Offshore Moorings applications.
Temperature
from -20°C (-4°F) to +82°C (+180°F).
Electrical Resistance
electrically discontinuous.
Construction
Tube: black, smooth, synthetic rubber, suitable for aromatic content up to 50%.
Reinforcement: high strength synthetic cord plus steel helix wire.
Cover: black, smooth (wrapped finish), synthetic rubber resistant to weathering, oil and sea water.
Reinforcement: high strength synthetic cord plus steel helix wire.
Cover: black, smooth (wrapped finish), synthetic rubber resistant to weathering, oil and sea water.
Branding: continuous yellow stripe “On Shore Filicudi Electrically Discontinuous EN 1765 S 15 - logo IVG” and marking according to specifications.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Bending radius | Vacuum | Length max | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | bar | m | ft | |
| 1237390 | 51 | 2 | 71 | 2,80 | 15 | 225 | 60 | 900 | 2,82 | 1,88 | 300 | 11,8 | 0,9 | 12 | 40 |
| 1308661 | 76 | 3 | 96 | 3,78 | 15 | 225 | 60 | 900 | 4,17 | 2,79 | 420 | 16,5 | 0,9 | 12 | 40 |
| 1237403 | 102 | 4 | 135,5 | 5,34 | 15 | 225 | 60 | 900 | 8,51 | 5,69 | 560 | 22,1 | 0,9 | 12 | 40 |
| 1237489 | 127 | 5 | 163 | 6,30 | 15 | 225 | 60 | 900 | 11,61 | 7,51 | 700 | 27,6 | 0,9 | 12 | 40 |
| 1237500 | 152 | 6 | 193,5 | 6,42 | 15 | 225 | 60 | 900 | 17,64 | 7,76 | 850 | 33,5 | 0,9 | 12 | 40 |
| 1237527 | 203 | 8 | 251,5 | 9,81 | 15 | 225 | 60 | 900 | 28,39 | 19,07 | 1100 | 43,3 | 0,9 | 12 | 40 |
