Dock oil hose Transoil

Regulations

  • BS 1435
  • EN 1765
  • RINA rules
BS 1435 type S 15.  EN 1765:2004 type S 15

RINA approved n. MAC014224CS.


Onshore
/ Onshore /

Transoil

Dock oil hose according to EN 1765 and BS 1435

Highlights

Each hose is tested
Supplied with fittings
Robust construction

Application

hardwall hose used for the suction and discharge of petroleum products from tankers and barges, bunkering service and industrial applications; suitable for aromatic content up to 50%. Realized with built-in fittings. Available also with swaged-on fittings. Not suitable for SubMarine – Offshore Moorings applications.

Temperature

from -20°C (-4°F) to +82°C (+180°F).

Electrical Resistance

electrically continuous.

Construction

Tube: black, smooth, synthetic rubber, suitable for aromatic content up to 50%.
Reinforcement: high strength synthetic cord, steel helix wire, and antistatic copper wires.
Cover: black, smooth (wrapped finish), synthetic rubber resistant to weathering, oil and sea water.
Branding: continuous yellow stripe “On Shore Transoil Electrically Continuous EN 1765 S 15 - logo IVG” and marking according to specifications.
Request information

I declare that I have read the privacy policy pursuant to EU Regulation 2016/679

Transoil_it.pdf
Transoil_en.pdf
Transoil_de.pdf
Transoil_fr.pdf
Transoil_ru.pdf
Transoil_cn.pdf
IVG_sd_onshore_offshore_it.pdfonshore_offshore_it.pdf
IVG_sd_onshore_offshore_en.pdfonshore_offshore_en.pdf
IVG_sd_onshore_offshore_ted.pdfonshore_offshore_ted.pdf
IVG_sd_onshore_offshore_fr.pdfonshore_offshore_fr.pdf
IVG_sd_onshore_offshore_cn.pdfonshore_offshore_cn.pdf
See all documents
Code Inside diameter Outside diameter Working pressure Burst pressure Weight nominal Bending radius Vacuum Length max
mm inch mm inch bar psi bar psi kg/m lbs/ft mm inch bar m ft
1297392 51 2 71 2,80 15 225 60 900 2,82 1,87 300 11,8 0,9 12 40
1298470 76 3 96 3,78 15 225 60 900 4,18 2,75 420 16,5 0,9 12 40
1215680 102 4 135,5 5,22 15 225 60 900 8,52 5,11 560 22,1 0,9 12 40
1090100 152 6 193,5 7,41 15 225 60 900 17,65 11,04 850 33,5 0,9 12 40
1090097 203 8 251,5 9,81 15 225 60 900 28,41 18,01 1100 43,3 0,9 12 40
