/ Oil /
SAE/100/R4
Hydraulic oil suction and delivery hose
Highlights
For hydraulic systems
Long lifespan
According to standard
Application
hardwall hose used for the suction and delivery of oil in hydraulic systems.
Temperature
from -40°C (-40°F) to +100°C (+212°F).
Construction
Tube: black, smooth, synthetic rubber, oil resistant (except ester base).
Reinforcement: high strength synthetic cord plus steel helix wire.
Cover: black, smooth (wrapped finish), synthetic rubber, weathering resistant.
Reinforcement: high strength synthetic cord plus steel helix wire.
Cover: black, smooth (wrapped finish), synthetic rubber, weathering resistant.
Branding: continuous embossed marking “IVG SAE 100 R4 / quarter and year of production”.
Available upon request
1.Different diameters.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Bending radius | Vacuum | Length max | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | bar | m | ft | |
| 1368559 | 16 | 5/8 | 27 | 1,06 | 21 | 315 | 84 | 1260 | 0,57 | 0,38 | 112 | 4,4 | 0,9 | 120 | 400 |
| 1453394 | 19 | 3/4 | 29,5 | 1,16 | 21 | 315 | 84 | 1260 | 0,59 | 0,40 | 120 | 4,7 | 0,9 | 120 | 400 |
| 1452800 | 25 | 1 | 35,5 | 1,40 | 17 | 255 | 68 | 1020 | 0,74 | 0,49 | 145 | 5,7 | 0,9 | 120 | 400 |
| 1407953 | 30 | 1-3/16 | 40,5 | 1,60 | 17 | 255 | 68 | 1020 | 0,79 | 0,53 | 180 | 7,1 | 0,9 | 120 | 400 |
| 1453610 | 32 | 1-1/4 | 42,5 | 1,67 | 14 | 210 | 56 | 840 | 0,9 | 0,60 | 195 | 7,7 | 0,9 | 120 | 400 |
| 1453149 | 38 | 1-1/2 | 49 | 1,93 | 10,5 | 158 | 42 | 630 | 1,11 | 0,74 | 228 | 9,0 | 0,9 | 120 | 400 |
| 1456652 | 40 | 1-37/64 | 51 | 2,01 | 10 | 150 | 40 | 600 | 1,16 | 0,78 | 240 | 9,5 | 0,9 | 120 | 400 |
| 1404962 | 45 | 1-49/64 | 56 | 2,21 | 7 | 105 | 28 | 420 | 1,26 | 0,85 | 270 | 10,6 | 0,9 | 120 | 400 |
| 1453378 | 51 | 2 | 62 | 2,44 | 7 | 105 | 28 | 420 | 1,43 | 0,96 | 300 | 11,8 | 0,9 | 120 | 400 |
| 1347179 | 60 | 2-3/8 | 72,5 | 2,86 | 4 | 60 | 16 | 240 | 2,12 | 1,43 | 335 | 13,2 | 0,9 | 120 | 400 |
| 1397869 | 63,5 | 2-1/2 | 76 | 2,99 | 4 | 60 | 16 | 240 | 2,14 | 1,46 | 355 | 14,0 | 0,9 | 120 | 400 |
| 1407783 | 76 | 3 | 88 | 3,47 | 4 | 60 | 16 | 240 | 2,56 | 1,75 | 455 | 17,9 | 0,9 | 120 | 400 |
| 1397850 | 90 | 3-35/64 | 103 | 4,06 | 3 | 45 | 12 | 180 | 3,37 | 2,26 | 530 | 20,9 | 0,9 | 120 | 400 |
| 1397842 | 102 | 4 | 115 | 4,53 | 2,5 | 38 | 10 | 150 | 3,78 | 2,58 | 610 | 24,0 | 0,9 | 120 | 400 |
