Fuel and oil delivery hose
Highlights
Good resistance to ageing
Length up to 120 m
Flexible for easy handling
Application
softwall hose used for the delivery of petroleum products with aromatic content up to 30%.
Temperature
from -20°C (-4°F) to +70°C (+158°F).
Construction
Tube: black, smooth, NBR rubber.
Reinforcement: high strength synthetic cord plus antistatic copper wire.
Cover: black, smooth (wrapped finish), synthetic rubber, weathering and oil resistant.
Reinforcement: high strength synthetic cord plus antistatic copper wire.
Cover: black, smooth (wrapped finish), synthetic rubber, weathering and oil resistant.
Branding: continuous yellow stripe “IVG (family logo)...”.
Available upon request
1.Different diameters
2.Different working pressures
3.Australia EN 1761:1999
4.Australia Reel hose (50% aromatic content)
5.Australia Super 50% aromatic content.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Length max | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | m | ft | |
| 1349287 | 13 | 1/2 | 20 | 0,79 | 10 | 150 | 30 | 450 | 0,24 | 0,16 | 120 | 400 |
| 1344269 | 19 | 3/4 | 27 | 1,06 | 10 | 150 | 30 | 450 | 0,36 | 0,24 | 120 | 400 |
| 1008463 | 25 | 1 | 35 | 1,38 | 10 | 150 | 30 | 450 | 0,62 | 0,42 | 120 | 400 |
| 1357930 | 32 | 1-1/4 | 42 | 1,65 | 10 | 150 | 30 | 450 | 0,76 | 0,51 | 120 | 400 |
| 1247808 | 38 | 1-1/2 | 48 | 1,89 | 10 | 150 | 30 | 450 | 0,82 | 0,55 | 120 | 400 |
| 1370154 | 51 | 2 | 61 | 2,40 | 10 | 150 | 30 | 450 | 1,06 | 0,71 | 120 | 400 |
| 1295497 | 63,5 | 2-1/2 | 74 | 2,92 | 10 | 150 | 30 | 450 | 1,39 | 0,93 | 120 | 400 |
| 1282832 | 76 | 3 | 89 | 3,51 | 10 | 150 | 30 | 450 | 2,03 | 1,36 | 120 | 400 |
| 1363344 | 90 | 3-35/64 | 105 | 4,14 | 10 | 150 | 30 | 450 | 2,7 | 1,83 | 120 | 400 |
| 1358006 | 102 | 4 | 115,5 | 4,55 | 10 | 150 | 30 | 450 | 2,8 | 1,88 | 120 | 400 |
| 1249800 | 127 | 5 | 143 | 5,63 | 10 | 150 | 30 | 450 | 4,12 | 2,77 | 120 | 400 |
| 1292242 | 152 | 6 | 172 | 6,78 | 10 | 150 | 30 | 450 | 6,05 | 4,06 | 120 | 400 |
