Australia EN 1360:13
Fuel and oil delivery hose
Highlights
Aromatic content up to 50%
Length up to 120 m
Also for refueling pumps
Application
softwall hose used for the delivery of petroleum products such as diesel, gasoline with aromatic content up to 50%. Also used in support of refueling pumps.
Temperature
from -30°C (-22°F) to +55°C (+131°F).
Electrical Resistance
R<1x102 Ω/application lengths, ensured by connecting the copper wires to the couplings.
Construction
Tube: black, smooth synthetic rubber.
Reinforcement: high strength synthetic cord plus antistatic copper wires.
Cover: black, smooth (wrapped finish), synthetic rubber, weathering and oil resistant.
Reinforcement: high strength synthetic cord plus antistatic copper wires.
Cover: black, smooth (wrapped finish), synthetic rubber, weathering and oil resistant.
Branding: continuous yellow stripe “IVG (family logo)...”.
Available upon request
1. Different diameters.
2. Australia Reel hose.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Length max | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | m | ft | |
| 1464370 | 16 | 5/8 | 28 | 1,10 | 16 | 240 | 48 | 720 | 0,54 | 0,37 | 120 | 400 |
| 1464361 | 19 | 3/4 | 31 | 1,22 | 16 | 240 | 48 | 720 | 0,62 | 0,42 | 120 | 400 |
| 1453114 | 25 | 1 | 37 | 1,46 | 16 | 240 | 48 | 720 | 0,76 | 0,52 | 120 | 400 |
