Genova global LL
Fuel and oil suction and delivery hose
Highlights
It complies with the regulations of various countries
Aromatic content up to 50%
Suitable for ATEX environment
Application
hardwall hose used for the suction delivery of unleaded gasoline and fuels with aromatic content up to 50%, suitable for use as a tank truck or tank wagon hose. Hose suitable for use in an ATEX environment. Tested by the notified body INERIS.
Temperature
-30°C (-22°F) +90°C (+194°F), w/peaks +110°C (+230°F).
Electrical Resistance
Ω/T, electrically conductive hose. Electrical resistance guaranteed for lengths equal or lower than 40m.
Construction
Tube: black, smooth, NBR1 conductive rubber.
Reinforcement: high strength synthetic cord plus steel helix wire.
Cover: black, smooth (wrapped finish), conductive, synthetic rubber, weathering, abrasion, ozone and oil resistant.
Reinforcement: high strength synthetic cord plus steel helix wire.
Cover: black, smooth (wrapped finish), conductive, synthetic rubber, weathering, abrasion, ozone and oil resistant.
Branding: continuous embossed marking according to one of above standards + continuous yellow brand “IVG Oil (family logo)...”.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Bending radius | Vacuum | Length max | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | bar | m | ft | |
| 1455141 | 19 | 3/4 | 32 | 1,26 | 16 | 240 | 64 | 960 | 0,76 | 0,51 | 120 | 4,7 | 0,9 | 120 | 400 |
| 1453823 | 25 | 1 | 38 | 1,50 | 16 | 240 | 64 | 960 | 0,94 | 0,63 | 150 | 5,9 | 0,9 | 120 | 400 |
| 1454650 | 32 | 1-1/4 | 45 | 1,77 | 16 | 240 | 64 | 960 | 1,13 | 0,77 | 175 | 6,9 | 0,9 | 120 | 400 |
| 1454455 | 38 | 1-1/2 | 52 | 2,05 | 16 | 240 | 64 | 960 | 1,43 | 0,97 | 225 | 8,9 | 0,9 | 120 | 400 |
| 1450026 | 50 | 1-31/32 | 65,5 | 2,58 | 16 | 240 | 64 | 960 | 2,03 | 1,37 | 275 | 10,8 | 0,9 | 120 | 400 |
| 1455133 | 63,5 | 2-1/2 | 78,5 | 3,09 | 16 | 240 | 64 | 960 | 2,58 | 1,74 | 300 | 11,8 | 0,9 | 120 | 400 |
| 1453998 | 75 | 2-61/64 | 90 | 3,55 | 16 | 240 | 64 | 960 | 3,08 | 2,08 | 350 | 13,8 | 0,9 | 120 | 400 |
| 1457012 | 100 | 3-15/16 | 116 | 4,57 | 16 | 240 | 64 | 960 | 4,4 | 2,97 | 450 | 17,7 | 0,9 | 120 | 400 |
