LPG/CORD/EN 1762/D
Gas delivery hose
Highlights
Length up to 60 m
For LPG and LNG
Available in stock
Application
softwall hose suitable for the delivery of liquefied petroleum gas, LPG (liquid or gas) and natural gas.
Temperature
from -30°C (-22°F) to +70°C (+158°F).
Electrical Resistance
electrical resistance below 1x106 Ω on service length assured through the rubber of cover (type Ω).
Construction
Tube: extruded, black, smooth, synthetic rubber.
Reinforcement: high strength synthetic cord.
Cover: black, smooth (wrapped finish), synthetic rubber, weathering and ozone resistant. Pin pricked cover to allow gas permeation.
Reinforcement: high strength synthetic cord.
Cover: black, smooth (wrapped finish), synthetic rubber, weathering and ozone resistant. Pin pricked cover to allow gas permeation.
Branding: continuous yellow brand “IVG - EN 1762:2018 - Type D - I.D W.P. bar - Ω - quarter and year of production”.
Available upon request
1.M version, with electrical resistance below 1 x 102 Ω on service length assured through the connection between copper wires and the fitted couplings.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Bending radius | Length max | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | m | ft | |
| 1425633 | 13 | 1/2 | 24 | 0,95 | 25 | 375 | 100 | 1500 | 0,39 | 0,26 | 100 | 3,9 | 60 | 200 |
| 1427482 | 19 | 3/4 | 32 | 1,26 | 25 | 375 | 100 | 1500 | 0,62 | 0,42 | 180 | 7,1 | 60 | 200 |
| 1414470 | 25 | 1 | 38 | 1,50 | 25 | 375 | 100 | 1500 | 0,77 | 0,52 | 200 | 7,9 | 60 | 200 |
| 1420321 | 32 | 1-1/4 | 46 | 1,81 | 25 | 375 | 100 | 1500 | 1,04 | 0,70 | 250 | 9,9 | 60 | 200 |
| 1420674 | 38 | 1-1/2 | 54 | 2,13 | 25 | 375 | 100 | 1500 | 1,35 | 0,91 | 320 | 12,6 | 60 | 200 |
| 1420666 | 50 | 1-31/32 | 67 | 2,64 | 25 | 375 | 100 | 1500 | 1,8 | 1,21 | 400 | 15,8 | 60 | 200 |
| 1421603 | 75 | 2-61/64 | 93 | 3,66 | 25 | 375 | 100 | 1500 | 2,7 | 1,81 | 650 | 25,6 | 60 | 200 |
| 1425730 | 100 | 4 | 122 | 4,81 | 25 | 375 | 100 | 1500 | 4,31 | 2,90 | 800 | 31,5 | 60 | 200 |
