Oil hose compressor

Regulations

  • MSHA
cover according to MSHA.
Oil
/ Oil /

Compressor

Hydraulic oil delivery hose

Highlights

Withstands high pressures
MSHA cover
Length up to 120 m

Application

softwall hose used in hydraulic systems to convey oil (except oil with ester base) at high temperatures, at a working pressure of 40 bar.

Temperature

from -30°C to +130°C. Intermittent service +150°C.

Construction

Tube: black, smooth, synthetic rubber.
Reinforcement: high strength synthetic cord.
Cover: blue, smooth (wrapped finish), auto-extinguishing synthetic rubber, weathering resistant.
Branding: continuous yellow stripe “IVG OIL COMPRESSOR W.P. 40 bar - B.P. 120 bar - TEMPERATURE + 130°C”.
Request information

I declare that I have read the privacy policy pursuant to EU Regulation 2016/679

Code Inside diameter Outside diameter Working pressure Burst pressure Weight nominal Length max
mm inch mm inch bar psi bar psi kg/m lbs/ft m ft
1396188 13 1/2 22 0,87 40 600 120 1800 0,32 0,22 120 400
1396170 19 19/32 31 1,22 40 600 120 1800 0,56 0,39 120 400
1396196 25 1 37 1,46 40 600 120 1800 0,7 0,48 120 400
1400258 32 1-1/4 46 1,81 40 600 120 1800 1,05 0,70 120 400
1400231 38 1-1/2 55 2,17 40 600 120 1800 1,49 1,00 120 400
1400240 51 2 67 2,64 40 600 120 1800 1,79 1,23 120 400
