Avio Global C
Aircraft refuelling hose, type C
Highlights
Suitable for reels
Length up to 60 m
It complies with the regulations of various countries
Application
softwall hose designed for the ground fuelling of aircrafts. The hose can be rolled up onto reels and is suitable to convey petroleum products and jet A1 fuel with aromatic content up to 50%.
Temperature
from -25°C (-13°F) to +70°C (+158°F).
Electrical Resistance
electrically conductive.
Construction
Tube: extruded, black, smooth, NBR rubber.
Reinforcement: high strength synthetic cord.
Cover: black, smooth (wrapped finish), antistatic synthetic rubber, resistant to weathering, abrasion and traces of oil.
Reinforcement: high strength synthetic cord.
Cover: black, smooth (wrapped finish), antistatic synthetic rubber, resistant to weathering, abrasion and traces of oil.
Branding: continuous yellow brand "IVG (family logo)..."- embossed marking with requested specification.
Available upon request
1.Avio Global type B, softwall conductive.
2. Fluorescent marking, which allows the visibility during night operations.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Min. reel size | Length max | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | m | ft | |
| 1455087 | 19 | 3/4 | 32 | 1,26 | 20 | 300 | 80 | 1200 | 0,59 | 0,40 | 225 | 8,9 | 60 | 200 |
| 1453475 | 25 | 1 | 38 | 1,50 | 20 | 300 | 80 | 1200 | 0,73 | 0,49 | 300 | 11,8 | 60 | 200 |
| 1453262 | 32 | 1-1/4 | 45 | 1,77 | 20 | 300 | 80 | 1200 | 0,9 | 0,60 | 375 | 14,8 | 60 | 200 |
| 1453041 | 38 | 1-1/2 | 52 | 2,05 | 20 | 300 | 80 | 1200 | 1,1 | 0,72 | 450 | 17,7 | 60 | 200 |
| 1450247 | 50 | 1-31/32 | 67 | 2,64 | 20 | 300 | 80 | 1200 | 1,74 | 1,14 | 550 | 21,7 | 60 | 200 |
| 1451928 | 63,5 | 2-1/2 | 80 | 3,15 | 20 | 300 | 80 | 1200 | 2,07 | 1,38 | 600 | 23,6 | 60 | 200 |
| 1453580 | 75 | 2-61/64 | 91 | 3,59 | 20 | 300 | 80 | 1200 | 2,32 | 1,56 | 600 | 23,6 | 60 | 200 |
| 1450255 | 100 | 3-15/16 | 118 | 4,65 | 20 | 300 | 80 | 1200 | 3,38 | 2,27 | 900 | 35,5 | 60 | 200 |
