Tallin
Hydraulic oil suction and delivery hose
Highlights
Rubber according to SAE J 517, type SAE 100 R4
For hydraulic systems
Long lifespan
Application
hardwall hose used for the suction and delivery of oil (except ester base) in hydraulic systems.
Temperature
from -40°C (-40°F) to +100°C (+212°F).
Construction
Tube: black, smooth, synthetic rubber, oil resistant.
Reinforcement: high strength synthetic cord plus steel helix wire.
Cover: black, smooth (wrapped finish), synthetic rubber, weathering resistant.
Reinforcement: high strength synthetic cord plus steel helix wire.
Cover: black, smooth (wrapped finish), synthetic rubber, weathering resistant.
Branding: continuous red stripe “IVG OIL (family logo)...”.
Available upon request
1.Different diameters.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Bending radius | Vacuum | Length max | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | bar | m | ft | |
| 1432559 | 19 | 3/4 | 28 | 1,10 | 10 | 150 | 30 | 450 | 0,51 | 0,34 | 95 | 3,7 | 0,9 | 120 | 400 |
| 1430157 | 25 | 1 | 34,5 | 1,36 | 10 | 150 | 30 | 450 | 0,67 | 0,45 | 125 | 4,9 | 0,9 | 120 | 400 |
| 1430629 | 32 | 1-1/4 | 41,5 | 1,64 | 8 | 120 | 24 | 360 | 0,83 | 0,56 | 160 | 6,3 | 0,9 | 120 | 400 |
| 1452410 | 38 | 1-1/2 | 48 | 1,89 | 8 | 120 | 24 | 360 | 1,02 | 0,69 | 185 | 7,3 | 0,9 | 120 | 400 |
| 1419510 | 40 | 1-37/64 | 50 | 1,97 | 8 | 120 | 24 | 360 | 1,07 | 0,72 | 195 | 7,7 | 0,9 | 120 | 400 |
| 1418998 | 45 | 1-49/64 | 55 | 2,17 | 6 | 90 | 18 | 270 | 1,19 | 0,80 | 198 | 7,8 | 0,9 | 120 | 400 |
| 1419293 | 51 | 2 | 61 | 2,40 | 6 | 90 | 18 | 270 | 1,33 | 0,89 | 200 | 7,9 | 0,9 | 120 | 400 |
| 1419676 | 60 | 2-3/8 | 71,5 | 2,82 | 5 | 75 | 15 | 225 | 2,08 | 1,39 | 315 | 12,4 | 0,9 | 120 | 400 |
| 1419668 | 76 | 3 | 88 | 3,47 | 5 | 75 | 15 | 225 | 2,88 | 1,93 | 380 | 15,0 | 0,9 | 120 | 400 |
