Regulations
ABS Product Design Assessment Nr. 23-2375199-PDA.
DNV Type Approval TAP00001E2.
ISO 15540.
/ Offshore /
PL EFESTO SD 25
Suction and delivery of seawater, mud, oil and petroleum products
Highlights
ABS and DNV approved
Outstanding flame resistance
Robust construction
Application
hardwall hose for the suction and delivery of seawater, mud, oil and petroleum products with maximum aromatic content up to 30%. Hose according to ISO 15540 for fire resistance at 800°C for 30'.
Temperature
from -30°C (-22°F) to +90°C(+194°F).
Construction
Tube: black, smooth, NBR rubber.
Reinforcement: high strength synthetic cord with embedded steel helix wire.
Cover: red, smooth (wrapped finish), flame retardant CR rubber. Resistance to weathering, abrasion, oil and seawater.
Reinforcement: high strength synthetic cord with embedded steel helix wire.
Cover: red, smooth (wrapped finish), flame retardant CR rubber. Resistance to weathering, abrasion, oil and seawater.
Branding:
in yellow "IVG Offshore (app logo)-PL EFESTO SD 25-ELECTRICALLY DISCONTINUOUS-ISO 15540- PDA Nr. 23-2375199-PDA -DNV GL TAP00001E2". Embossed "IVG Offshore-M/Y-PL EFESTO SD 25-I.D.-W.P.-TEMP".
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Bending radius | Vacuum | Length max | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | bar | m | ft | |
| 1481282 | 19 | 3/4 | 56 | 2,21 | 25 | 375 | 105 | 1575 | 2,58 | 1,73 | 160 | 6,3 | 0,9 | 60 | 200 |
| 1476564 | 25 | 1 | 62 | 2,44 | 25 | 375 | 105 | 1575 | 2,99 | 2,01 | 210 | 8,3 | 0,9 | 60 | 200 |
| 1476360 | 51 | 2 | 90 | 3,55 | 25 | 375 | 105 | 1575 | 5,09 | 3,42 | 410 | 16,2 | 0,9 | 60 | 200 |
| 1474421 | 76 | 3 | 116 | 4,57 | 25 | 375 | 105 | 1575 | 7,39 | 4,97 | 625 | 24,6 | 0,9 | 60 | 200 |
| 1475533 | 102 | 4 | 147 | 5,79 | 25 | 375 | 105 | 1575 | 13,29 | 8,93 | 830 | 32,7 | 0,9 | 60 | 200 |
| 1476378 | 152 | 6 | 204 | 8,04 | 25 | 375 | 105 | 1575 | 22,44 | 15,08 | 1380 | 54,4 | 0,9 | 60 | 200 |
| 1478036 | 203 | 8 | 255 | 10,05 | 25 | 375 | 105 | 1575 | 30,45 | 20,46 | 1830 | 72,1 | 0,9 | 30 | 100 |
