Regulations
Phthalates free (REACH Reg.).
PAHs free (acc. to ZEK 01.4-08 Cat. 1). Reg. EC 1935/2004. Reg. EC 2023/2006.
/ Offshore /
PL POTABLE SD FLOATING D1
Self floating suction and delivery hose for potable water
Highlights
ABS approved
Self-floating
Compliant with food regulations
Application
self floating hardwall hose used for the suction and delivery of drinking water from ship to oil rig. The reserve buoyancy is calculated following the OCIMF standard. Tensile breaking load: 2000 kgf for inside diameter 2", 4000 kgf for inside diameter 3", 7000 kgf for inside diameter 4".
Temperature
from -40°C (-40°F) to +100°C (+212°F).
Construction
Tube: white, smooth, food quality IIR rubber.
Reinforcement: high strength synthetic cord plus steel helix wire.
Cover: orange, smooth (wrapped finish), EPDM rubber, weathering, ozone, and sea-water resistant.
Reinforcement: high strength synthetic cord plus steel helix wire.
Cover: orange, smooth (wrapped finish), EPDM rubber, weathering, ozone, and sea-water resistant.
Branding:
white stripe "IVG Offshore(family logo)-PL POTABLE SD FLOATING D1-ELECTRICALLY DISCONTINUOUS-PDA Nr. 23-2375199-PDA". Embossed marking "IVG Offshore-M/Y-PL POTABLE SD FLOATING D1-I.D.-W.P.-TEMP.".
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Bending radius | Vacuum | Length max | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | bar | m | ft | |
| 1481436 | 51 | 2 | 121,5 | 20 | 300 | 80 | 1200 | 5,54 | 3,83 | 450 | 17,7 | 0,9 | 60 | 200 |
| 1481444 | 76 | 3 | 143 | 20 | 300 | 80 | 1200 | 6,93 | 4,63 | 700 | 27,6 | 0,9 | 60 | 200 |
| 1465236 | 102 | 4 | 187 | 20 | 300 | 80 | 1200 | 10,43 | 7,01 | 900 | 35,5 | 0,9 | 60 | 200 |
