Regulations
ABS Product Design Assessment Nr. 23-2375199-PDA.
/ Offshore /
PL ABRASIVE SD 20
Suction and discharge of abrasive materials
Highlights
ABS approved
It resists abrasion
It resists traction
Application
hardwall hose designed to convey barite and bentonite and other abrasive materials from ship to oil rigs to consolidate the oil well. Tensile breaking load: 7000 kgf.
Temperature
from -25°C (-13°F) to +70°C (+158°F).
Construction
Tube: black, smooth, abrasion resistant NR/SBR rubber.
Reinforcement: high strength synthetic cord, steel helix wire, and antistatic copper wire.
Cover: black, smooth (wrapped finish), EPDM rubber, weathering, ozone, and sea-water resistant.
Reinforcement: high strength synthetic cord, steel helix wire, and antistatic copper wire.
Cover: black, smooth (wrapped finish), EPDM rubber, weathering, ozone, and sea-water resistant.
Branding:
continuous red stripe "IVG Offshore (family logo) - PL ABRASIVE SD 20 - PDA Nr. 23-2375199-PDA". Embossed marking "IVG Offshore - M/Y - PL ABRASIVE SD 20 - I.D. - W.P. - TEMP.".
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Bending radius | Vacuum | Length max | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | bar | m | ft | |
| 1467751 | 102 | 4 | 126 | 4,96 | 20 | 300 | 80 | 1200 | 6,52 | 4,38 | 510 | 20,1 | 0,9 | 120 | 400 |
| 1467840 | 127 | 5 | 155 | 6,11 | 20 | 300 | 80 | 1200 | 8,59 | 5,77 | 635 | 25,0 | 0,9 | 60 | 200 |
