Regulations
Phthalates free (REACH Reg.).
PAHs free (acc. to ZEK 01.4-08 Cat. 1). Reg. EC 1935/2004. Reg. EC 2023/2006.
/ Offshore /
PL Potable LL
Potable water suction and delivery hose
Highlights
Compliant with food regulations
High visibility
Excellent for marine environment
Application
hardwall hose used for the suction and delivery of drinking water from ship to oil rig.
Temperature
from -40°C (-40°F) to +100°C (+212°F).
Construction
Tube: white, smooth, food quality IIR rubber.
Reinforcement: high strength synthetic cord divided by a layer of rubber plus steel helix wire.
Cover: orange, smooth (wrapped finish), synthetic rubber, weathering, ozone, and sea-water resistant.
Reinforcement: high strength synthetic cord divided by a layer of rubber plus steel helix wire.
Cover: orange, smooth (wrapped finish), synthetic rubber, weathering, ozone, and sea-water resistant.
Branding: continuous white/red stripe “IVG Offshore (family logo)...”.
Available upon request
1.Different diameters.
2.Different working pressures.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Bending radius | Vacuum | Length max | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | bar | m | ft | |
| 1452657 | 51 | 2 | 69 | 2,72 | 17 | 255 | 51 | 765 | 2,45 | 1,65 | 250 | 9,9 | 0,9 | 60 | 200 |
| 1460277 | 76 | 3 | 94,5 | 3,72 | 17 | 255 | 51 | 765 | 3,66 | 2,54 | 400 | 15,8 | 0,9 | 60 | 200 |
| 1334190 | 102 | 4 | 125 | 4,93 | 17 | 255 | 51 | 765 | 7,02 | 4,63 | 555 | 21,9 | 0,9 | 60 | 200 |
| 1334204 | 127 | 5 | 153,5 | 6,07 | 17 | 255 | 51 | 765 | 9,75 | 6,45 | 730 | 28,8 | 0,9 | 60 | 200 |
