Regulations
Flame retardant according to ASTM C-542.
SAE J20 R2.
/ Hot /
Flexisil LL
Suction and delivery hose for cooling systems
Highlights
Silicon rubber
Flame retardant
Shiny finish
Application
hardwall suction and delivery silicone hose designed for conveying hot air, exhaust gas or fluids like water mixed with anti-freeze liquids, with good oil resistance. Suitable to be used in cooling systems of cars and industrial vehicle engines, where high temperature resistance is required. (Temperature range for water and anti-freeze liquids: from -40°C/-40°F to +100°C/212°F).
Temperature
from -50°C (-58°F) to +200°C (+392°F), for few minutes peaks up to +220°C (+428°F).
Construction
Tube: red, smooth, silicone.
Reinforcement: synthetic cord and helix wire.
Cover: red, shiny, silicone rubber.
Reinforcement: synthetic cord and helix wire.
Cover: red, shiny, silicone rubber.
Branding: continuous white stripe “IVG Hot (family logo)...”.
Available upon request
1.Different diameters.
2.Hardwall version with corrugated cover.
3.Different colours.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Bending radius | Vacuum | Length max | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | bar | m | ft | |
| 1484052 | 13 | 1/2 | 25 | 0,99 | 3 | 45 | 9 | 135 | 0,41 | 0,28 | 80 | 3,2 | 0,9 | 60 | 200 |
| 1600130 | 16 | 5/8 | 28 | 1,10 | 3 | 45 | 9 | 135 | 0,47 | 0,31 | 100 | 3,9 | 0,9 | 60 | 200 |
| 1482122 | 19 | 3/4 | 31 | 1,22 | 3 | 45 | 9 | 135 | 0,55 | 0,37 | 120 | 4,7 | 0,9 | 60 | 200 |
| 1600328 | 25 | 1 | 37 | 1,46 | 3 | 45 | 9 | 135 | 0,68 | 0,45 | 150 | 5,9 | 0,9 | 60 | 200 |
| 1478214 | 32 | 1-1/4 | 44 | 1,73 | 3 | 45 | 9 | 135 | 0,83 | 0,56 | 190 | 7,5 | 0,9 | 60 | 200 |
| 1474839 | 51 | 2 | 64 | 2,52 | 3 | 45 | 9 | 135 | 1,37 | 0,92 | 300 | 11,8 | 0,9 | 60 | 200 |
| 1475282 | 63,5 | 2-1/2 | 77 | 3,03 | 3 | 45 | 9 | 135 | 1,78 | 1,20 | 380 | 15,0 | 0,9 | 60 | 200 |
| 1473166 | 76 | 3 | 89 | 3,51 | 3 | 45 | 9 | 135 | 2,19 | 1,47 | 460 | 18,1 | 0,9 | 60 | 200 |
