Regulations
Phthalates free (REACH Reg.).
Heavy metal tested. PAHs free (acc. to ZEK 01.4-08 Cat. 1). Reg. EC 1935/2004. Reg. EC 2023/2006.
/ Food /
Tuscany
Low friction
Highlights
Low coefficient of friction
External spiral in thermoplastic material
Robust structure
Application
flexible, hardwall, corrugated hose for the suction and delivery of non fatty foods, in particular vintage wines and alcohols at 96°. The external plastic helix wire on the cover reduces friction against abrasive and rough surfaces, suitable to be used both indoors and outdoors. Shiny finish. It is not crush resistant.
Temperature
from -40°C (-40°F) to +120°C (+248°F).
Construction
Tube: white, smooth, food quality, taste free and odourless IIR rubber.
Reinforcement: high strength synthetic cord plus steel helix wire.
Cover: red, corrugated, synthetic rubber with low friction coefficient thermoplastic external yellow helix. Weathering and abrasion resistant.
Reinforcement: high strength synthetic cord plus steel helix wire.
Cover: red, corrugated, synthetic rubber with low friction coefficient thermoplastic external yellow helix. Weathering and abrasion resistant.
Branding: length supplied with marking according to EU traceability requirements.
Available upon request
1. Supplied in service lengths with soft ends.
| Code | Inside diameter | Working pressure | Burst pressure | Weight nominal | Bending radius | Vacuum | Length max | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | bar | m | ft | |
| 1478176 | 51 | 2 | 10 | 150 | 30 | 450 | 2,14 | 1,44 | 150 | 5,9 | 0,8 | 60 | 200 |
| 1481126 | 60 | 2-3/8 | 10 | 150 | 30 | 450 | 2,46 | 1,65 | 180 | 7,1 | 0,8 | 60 | 200 |
| 1479687 | 63,5 | 2-1/2 | 10 | 150 | 30 | 450 | 2,58 | 1,73 | 190 | 7,5 | 0,8 | 60 | 200 |
| 1479105 | 76 | 3 | 10 | 150 | 30 | 450 | 3,13 | 2,10 | 230 | 9,1 | 0,8 | 60 | 200 |
| 1479318 | 80 | 3-5/32 | 10 | 150 | 30 | 450 | 3,28 | 2,20 | 240 | 9,5 | 0,8 | 60 | 200 |
| 1482750 | 102 | 4 | 10 | 150 | 30 | 450 | 4,13 | 2,78 | 400 | 15,8 | 0,8 | 60 | 200 |
