Regulations
Tested and homologated by BNIC.
FDA tit. 21 it. 177.1520 for foods.Phthalates free (REACH Reg.).
Reg. EC 1935/2004. Reg. EC 2023/2006. Reg. EU 10/2011 aqueous, fatty and alcoholic foods up to 96% vol.
/ Food /
Shetland
Premium suction and delivery hose for alcohols
Highlights
Approved by BNIC
Specific for alcohols
Available with corrugated cover
Application
hardwall hose for suction and delivery of alcohols at 96% with no alterations of taste and odour.
Temperature
from -30°C (-22°F) to +80°C (+176°F).
Construction
Tube: white, smooth, food quality plastomer, taste free and odourless.
Reinforcement: high strength synthetic cord, helix wire, and antistatic copper wire.
Cover: red, smooth (wrapped finish), synthetic rubber, weathering resistant.
Reinforcement: high strength synthetic cord, helix wire, and antistatic copper wire.
Cover: red, smooth (wrapped finish), synthetic rubber, weathering resistant.
Branding: continuous blue/white stripe “IVG Food (family logo)...”.
Available upon request
1.Different diameters.
2.Shetland ond, with blue corrugated cover and reduced bending radius.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Bending radius | Vacuum | Length max | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | bar | m | ft | |
| 1419960 | 25 | 1 | 36,5 | 1,44 | 10 | 150 | 30 | 450 | 0,84 | 0,56 | 105 | 4,1 | 0,9 | 60 | 200 |
| 1419951 | 38 | 1-1/2 | 50,5 | 1,99 | 10 | 150 | 30 | 450 | 1,38 | 0,94 | 175 | 6,9 | 0,9 | 60 | 200 |
| 1417991 | 51 | 2 | 65 | 2,56 | 10 | 150 | 30 | 450 | 1,91 | 1,28 | 250 | 9,9 | 0,9 | 60 | 200 |
| 1431153 | 63,5 | 2-1/2 | 78 | 3,07 | 10 | 150 | 30 | 450 | 2,54 | 1,71 | 330 | 13,0 | 0,9 | 60 | 200 |
| 1419943 | 70 | 2-3/4 | 84,5 | 3,33 | 10 | 150 | 30 | 450 | 2,77 | 1,86 | 390 | 15,4 | 0,9 | 60 | 200 |
