Food products hose Millennium

Regulations

  • 3-A Sanitary Standards
  • BfR
  • BPA free
  • D.M.21/03/73
  • FDA
  • Reg. CE 1907/2006 (REACH)
  • Reg. CE 1907/2006 (REACH)
  • Reg. CE 1907/2006 (REACH)
  • Reg. CE 1935/2004
  • Reg. CE 2023/2006
3-A Sanitary Std. N°18-03 CLASS II.  BfR XXI Cat.2 for foods  Bisphenol A free.  D.M. 21/03/73 aqueous, fatty foods and alcohol up to 96% vol.  FDA tit.21 art. 177.2600 aqueous and fatty foods.  Heavy metal tested.  PAHs free (acc. to ZEK 01.4-08 Cat. 1).

Phthalates free (REACH Reg.).

  Reg. EC 1935/2004.  Reg. EC 2023/2006.
Food
/ Food /

Millennium

TOTAL FOOD, perfect for all food products

Highlights

Total food
Safe and durable
Complies with all regulations

Application

softwall hose for delivery of many food products as olive oil, wine, beer, fruit juices, fatty foods, milk and alcohol up to 96°.

Temperature

from -30°C (-22°F) to +100°C (212°F).

Construction

Tube: white, smooth, food quality, taste free and odourless synthetic rubber. 100% phthalates free.
Reinforcement: high strength synthetic cord, separated by a layer of rubber.
Cover: blue, smooth (wrapped finish) synthetic rubber, ozone and weathering resistant.
Branding: white/red/gold continuous stripe "IVG Food (family logo) Millennium..."
Request information

I declare that I have read the privacy policy pursuant to EU Regulation 2016/679

Millennium_it.pdf
Millennium_en.pdf
Millennium_de.pdf
Millennium_fr.pdf
Millennium_ru.pdf
Millennium_cn.pdf
IVG_sd_CIP_it.pdfCIP_it.pdf
IVG_sd_cip-en.pdfcip-en.pdf
IVG_sd_CIP_ted.pdfCIP_ted.pdf
IVG_sd_CIP_fr.pdfCIP_fr.pdf
IVG_sd_CIP_cn.pdfCIP_cn.pdf
See all documents
Code Inside diameter Outside diameter Working pressure Burst pressure Weight nominal Length max
mm inch mm inch bar psi bar psi kg/m lbs/ft m ft
1477340 16 5/8 30 1,18 10 150 30 450 0,59 0,39 60 200
1466941 19 3/4 33 1,30 10 150 30 450 0,67 0,44 60 200
1474251 25 1 39 1,54 10 150 30 450 0,82 0,55 60 200
1474260 32 1-1/4 46 1,81 10 150 30 450 1,01 0,68 60 200
1474278 38 1-1/2 52 2,05 10 150 30 450 1,16 0,78 60 200
1300078 40 1-37/64 54 2,13 10 150 30 450 1,21 0,81 60 200
1464264 51 2 65,5 2,58 10 150 30 450 1,56 1,05 60 200
1300080 60 2-3/8 76,5 3,01 10 150 30 450 2,05 1,38 60 200
1481231 63,5 2-1/2 80 3,15 10 150 30 450 2,18 1,46 60 200
1474286 76 3 94 3,70 10 150 30 450 2,78 1,86 60 200
1486195 80 3-5/32 98 3,86 10 150 30 450 2,91 1,95 60 200
1300084 100 3-15/16 118 4,65 10 150 30 450 3,55 2,39 60 200
