Regulations
D.M. 21/03/73 aqueous, fatty foods and alcohol up to 95% vol.
3-A Sanitary Std. N°18-03 CLASS II.Arrêté Français 05/08/2020 cat. D.
BfR ed. 21 - XXI Cat. 2 for fatty foods.
Bisphenol A free. D.M. 21/03/73 aqueous, fatty foods and alcohol up to 96% vol. FDA tit.21 art. 177.2600 aqueous and fatty foods.Japan Ministry of Health and Welfare Notification No. 370, 1959–Specific. and Standards for Food, Food Additives, Etc. T<100°C.
Phthalates free (REACH Reg.).
Heavy metal tested. Reg. EC 1935/2004. Reg. EC 2023/2006.
/ Food /
Dijon LL
High quality multipurpose food hose
Highlights
High level of purity
Suitable for all food products
Compliant with all food standards
Application
hardwall hose for suction and delivery of many food products as olive oil, wine, beer, fruit juices, fatty foods, milk and alcohol up to 95°. Suitable for loading-unloading operations in tank truck transport processes and in food industry plants.
Temperature
from -30°C (-22°F) to +100°C (+212°F).
Construction
Tube: white, smooth, food quality, taste free and odourless synthetic rubber. 100% phthalates free.
Reinforcement: high strength synthetic cord and embedded helix wire.
Cover: blue, smooth (wrapped finish) food quality synthetic rubber, ozone and weathering resistant.
Reinforcement: high strength synthetic cord and embedded helix wire.
Cover: blue, smooth (wrapped finish) food quality synthetic rubber, ozone and weathering resistant.
Branding: white/red/gold continuous stripe "IVG Food (family logo) Dijon LL...".
Available upon request
- "Easy" hose with corrugated cover.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Bending radius | Vacuum | Length max | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | bar | m | ft | |
| 1501135 | 25 | 1 | 36,5 | 1,44 | 10 | 150 | 30 | 450 | 0,93 | 0,62 | 75 | 3,0 | 0,9 | 60 | 200 |
| 1500023 | 32 | 1 1/4 | 43,5 | 1,71 | 10 | 150 | 30 | 450 | 1,17 | 0,79 | 100 | 3,9 | 0,9 | 60 | 200 |
| 1492560 | 38 | 1-1/2 | 49,5 | 1,95 | 10 | 150 | 30 | 450 | 1,35 | 0,89 | 120 | 4,7 | 0,9 | 60 | 200 |
| 1498266 | 51 | 2 | 63,5 | 2,50 | 10 | 150 | 30 | 450 | 2,12 | 1,42 | 170 | 6,7 | 0,9 | 60 | 200 |
| 1498401 | 63,5 | 2 1/2 | 77 | 3,03 | 10 | 150 | 30 | 450 | 2,71 | 1,82 | 235 | 9,3 | 0,9 | 60 | 200 |
| 1498673 | 76 | 3 | 91 | 3,58 | 10 | 150 | 30 | 450 | 3,48 | 2,34 | 300 | 11,8 | 0,9 | 60 | 200 |
| 2300069 | 102 | 4 | 117,5 | 4,63 | 10 | 150 | 30 | 450 | 4,65 | 3,12 | 400 | 15,8 | 0,9 | 60 | 200 |
