Chicago BS 3169
Booster hose for fire fighting fluids
Highlights
Robust and flexible
Long lifespan
Length up to 120 m
Application
a robust and flexible softwall reel booster hose as fitted on fire fighting trucks, for the delivery of water and extinguishing fluids.
Temperature
from -40°C (-40°F) to +70°C (+158°F).
Construction
Tube: black, smooth, SBR rubber, resistant to chemical products and fire extinguishing foams.
Reinforcement: high strength synthetic cord.
Cover: black, smooth, (wrapped finish) EPDM rubber, weathering and abrasion resistant.
Reinforcement: high strength synthetic cord.
Cover: black, smooth, (wrapped finish) EPDM rubber, weathering and abrasion resistant.
Branding: continuous embossed marking “IVG/BS 3169:1986 A2/I.D./month and year of manufacture/40 bar”.
Available upon request
1.Different diameters.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Min. reel size | Length max | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | m | ft | |
| 1400320 | 19 | 3/4 | 32,5 | 1,28 | 40 | 600 | 120 | 1800 | 0,64 | 0,43 | 150 | 5,9 | 120 | 400 |
| 1408216 | 25 | 1 | 38,5 | 1,52 | 40 | 600 | 120 | 1800 | 0,78 | 0,53 | 150 | 5,9 | 120 | 400 |
