Ankara/EN 694 A1 - Fire

Regulations

  • EN 694
EN 694 Type A Class 1.
Fire
/ Fire /

Ankara/EN 694 A1

Fire fighting hose for fixed installations

Highlights

Suitable for reels
Long lifespan
Length up to 120 m

Application

softwall reel booster hose for the delivery of water and extinguishing fluids. The hose is designed for fixed fire fighting systems used in buildings and civil works.

Temperature

from -20°C (-4°F) to +60°C (+140°F).

Construction

Tube: black, smooth, EPDM rubber, resistant to chemical products and fire extinguishing foams.
Reinforcement: high strength synthetic cord.
Cover: black, smooth, (wrapped finish) EPDM rubber, weathering and abrasion resistant.
Branding: continuous embossed marking “IVG EN 694:2014 - TYPE A CL 1 - I.D. - ... MPA (... BAR) - quarter and year of manufacture”.
Request information

I declare that I have read the privacy policy pursuant to EU Regulation 2016/679

Code Inside diameter Outside diameter Working pressure Burst pressure Weight nominal Min. reel size Length max
mm inch mm inch bar psi bar psi kg/m lbs/ft mm inch m ft
2000074 19 3/4 34 1,34 12 180 42 630 0,73 0,49 200 7,9 120 400
1397990 25 1 40 1,58 12 180 42 630 0,9 0,60 200 7,9 120 400
2000075 33 1-19/64 47 1,85 7 105 24,5 368 1 0,67 280 11,0 120 400
