Chicago glow EN 1947
Booster hose for fire fighting fluids - fully luminescent cover
Highlights
Visible in the dark
Length up to 120 m
Long lifespan
Application
a robust and flexible softwall reel booster hose as fitted on fire fighting trucks for the delivery of water and extinguishing fluids. The rubber cover luminescent allows safe use even in low visibility conditions.
Temperature
-20°C (-4°F) to +60°C (+140°F).
Construction
Tube: black, smooth, EPDM rubber, resistant to chemical products and fire extinguishing foams.
Reinforcement: high strength synthetic cord.
Cover: light yellow, luminescent, smooth, (wrapped finish) synthetic rubber, weathering resistant
Reinforcement: high strength synthetic cord.
Cover: light yellow, luminescent, smooth, (wrapped finish) synthetic rubber, weathering resistant
Branding: continuous embossed marking “IVG EN 1947:2014 - 2 - C - 1 - I.D. - 40 bar - quarter and year of manufacture” + black IVG tape.
Available upon request
1.Different diameters.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Length max | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | m | ft | |
| 1475215 | 19 | 3/4 | 32,5 | 1,28 | 40 | 600 | 120 | 1800 | 0,64 | 0,43 | 120 | 400 |
| 1476327 | 25 | 1 | 38,5 | 1,52 | 40 | 600 | 120 | 1800 | 0,79 | 0,53 | 120 | 400 |
| 201200836 | 33 | 1 19/64 | 46,5 | 1,83 | 40 | 600 | 120 | 1800 | 0,98 | 0,66 | 120 | 400 |
