Chemical products hose Supertop upe cond/LL

Regulations

  • EN 12115
EN 12115:2021.
Chem
/ Chem /

Supertop upe cond/LL

Conductive hose to convey chemicals and petroleum products, PE-UHMW tube

Highlights

It can be used in ATEX areas
Complies with EN 12115
Tested and approved by INERIS

Application

hardwall smooth hose to convey a wide range of aggressive chemicals, solvents, petroleum products and oils. Normally installed on tank trucks and discharge platforms in chemical and oil industries.

Hose suitable for use in an ATEX environment. Tested by the notified body INERIS.

Temperature

-40°C (-40°F) +100°C (+212°F) depending on medium.

Electrical Resistance

Ω/T, electrically conductive hose. Electrical resistance for lengths equal to or lower than 40 m.

Construction

Tube: black, smooth, high weight polyethylene (PE-UHMW). Chemical resistance according to IVG chemical resistance chart. For temperature exceeding 50°C contact IVG.
Reinforcement: high strength synthetic cord and steel helix wire.
Cover:

black, smooth (wrapped finish), EPDM rubber, resistant to chemicals, abrasion, weathering and ozone.


Branding: blue/white stripe “IVG Chem Supertop-upe cond/LL...”. Embossed branding according to EN 12115.
Request information

I declare that I have read the privacy policy pursuant to EU Regulation 2016/679

Supertop_UPE_Cond_LL_it.pdf
Supertop_UPE_Cond_LL_en.pdf
Supertop_UPE_Cond_LL_de.pdf
Supertop_UPE_Cond_LL_fr.pdf
Supertop_UPE_Cond_LL_ru.pdf
Supertop_UPE_Cond_LL_cn.pdf
IVG_sd_atex_it.pdfatex_it.pdf
IVG_sd_atex-en.pdfatex-en.pdf
IVG_sd_atex_ted.pdfatex_ted.pdf
IVG_sd_atex_fr.pdfatex_fr.pdf
IVG_sd_atex_cn.pdfatex_cn.pdf
See all documents
Code Inside diameter Outside diameter Working pressure Burst pressure Weight nominal Bending radius Vacuum Length max
mm inch mm inch bar psi bar psi kg/m lbs/ft mm inch bar m ft
1429760 19 3/4 31 1,22 16 240 64 960 0,69 0,47 90 3,5 0,9 60 200
1417401 25 1 38 1,50 16 240 64 960 0,89 0,61 120 4,7 0,9 60 200
1427822 32 1-1/4 44 1,73 16 240 64 960 1,03 0,70 150 5,9 0,9 60 200
1426788 38 1-1/2 51 2,01 16 240 64 960 1,31 0,91 180 7,1 0,9 60 200
1464302 51 2 65 2,56 16 240 64 960 1,78 1,20 280 11,0 0,9 60 200
1451162 63,5 2-1/2 78 3,07 16 240 64 960 2,33 1,57 320 12,6 0,9 60 200
1434098 75 2-61/64 90 3,55 16 240 64 960 2,8 1,89 400 15,8 0,9 60 200
1455575 102 4 118 4,65 16 240 64 960 4,31 2,90 550 21,7 0,9 60 200
