Chemical products hose Thunderflex

Regulations

  • BPA free
  • EN 12115
  • FDA
  • Reg. CE 1907/2006 (REACH)
  • Reg. CE 1935/2004
  • Reg. CE 2023/2006

Reg. EU 10/2011 for alcoholic foods up to 95% vol.

  Bisphenol A free.  EN 12115:2021.  FDA tit. 21 it. 177.1520 for foods.

Phthalates free (REACH Reg.).

  Tube: Reg. EC 1935/2004.  Tube: Reg. EC 2023/2006.
Chem
/ Chem /

Thunderflex

Conductive hose for chemicals, food, petroleum, PE-UHMW tube

Highlights

It can be used in ATEX areas
Suitable for a wide range of chemicals
Complies with EN 12115

Application

hardwall smooth hose to convey a wide range of chemicals, food, petroleum products and oils.

Hose suitable for use in an ATEX environment. Tested by the notified body INERIS.

Temperature

-30°C(-22°F) +100°C(212°F) depending on medium.

Electrical Resistance

Ω/T, electrically conductive hose. Electrical resistance for lengths equal to or lower than 40 m.

Construction

Tube: black and white speckled, smooth, food quality PE-UHMW. Chemical resistance according to IVG chemical resistance chart. For temperature exceeding 50°C contact IVG.
Reinforcement: high strength synthetic cord plus steel helix wire.
Cover: black, smooth (wrapped finish), EPDM rubber, resistant to chemicals, abrasion, weathering and ozone.
Branding: continuous blue/white stripe “IVG Chem THUNDERFLEX...”. Embossed according to EN 12115.
Request information

I declare that I have read the privacy policy pursuant to EU Regulation 2016/679

Thunderflex__it.pdf
Thunderflex__en.pdf
Thunderflex__de.pdf
Thunderflex__fr.pdf
Thunderflex__ru.pdf
Thunderflex__cn.pdf
IVG_sd_atex_it.pdfatex_it.pdf
IVG_sd_CIP_it.pdfCIP_it.pdf
IVG_sd_atex-en.pdfatex-en.pdf
IVG_sd_cip-en.pdfcip-en.pdf
IVG_sd_atex_ted.pdfatex_ted.pdf
IVG_sd_CIP_ted.pdfCIP_ted.pdf
IVG_sd_atex_fr.pdfatex_fr.pdf
IVG_sd_CIP_fr.pdfCIP_fr.pdf
IVG_sd_atex_cn.pdfatex_cn.pdf
IVG_sd_CIP_cn.pdfCIP_cn.pdf
See all documents
Code Inside diameter Outside diameter Working pressure Burst pressure Weight nominal Bending radius Vacuum Length max
mm inch mm inch bar psi bar psi kg/m lbs/ft mm inch bar m ft
1466216 13 1/2 25 0,99 16 240 64 960 0,52 0,35 60 2,4 0,9 60 200
1476823 16 5/8 28 1,10 16 240 64 960 0,6 0,40 75 3,0 0,9 60 200
1463063 19 3/4 31 1,22 16 240 64 960 0,67 0,46 90 3,5 0,9 60 200
1451847 25 1 38 1,50 16 240 64 960 0,91 0,61 120 4,7 0,9 60 200
1456156 32 1-1/4 44 1,73 16 240 64 960 1,01 0,68 150 5,9 0,9 60 200
1463071 38 1-1/2 51 2,01 16 240 64 960 1,31 0,89 180 7,1 0,9 60 200
1465171 40 1-37/64 53 2,09 16 240 64 960 1,36 0,93 180 7,1 0,9 60 200
1456148 51 2 65 2,56 16 240 64 960 1,77 1,19 250 9,9 0,9 60 200
1464981 63,5 2-1/2 78 3,07 16 240 64 960 2,39 1,59 320 12,6 0,9 60 200
1466232 76 3 91 3,59 16 240 64 960 2,9 1,93 400 15,8 0,9 60 200
1476343 100 3-15/16 116 4,57 16 240 64 960 4,26 2,86 550 21,7 0,9 60 200
