Poseidon LL
Fuel suction and delivery hose, fire resistant, used in pleasure boats
Highlights
Permeation resistant
Excellent bending radius
Aromatic content up to 50%
Application
hardwall hose suitable to convey fuel with an aromatic content up to 50% in pleasure boats up to 24m length. Suitable to be installed even with narrow bending radius.
Temperature
from -30°C (-22°F) to +100°C (+212°F).
Construction
Tube: black, smooth, synthetic rubber.
Reinforcement: high strength synthetic cord plus steel helix wire.
Cover: black, smooth (wrapped finish), self-extinguishing synthetic rubber, oil, abrasion, and weathering resistant.
Reinforcement: high strength synthetic cord plus steel helix wire.
Cover: black, smooth (wrapped finish), self-extinguishing synthetic rubber, oil, abrasion, and weathering resistant.
Branding:
continuous yellow stripe “IVG BOAT POSEIDON LL - year - id - ISO 7840:21 A1 E10/B10 compatible- CE N.DIP189423VE/002 RINA - SAE J 1527:22 - USCG Type A1 - NMMA Type accepted”.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Bending radius | Length max | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | m | ft | |
| 1441370 | 13 | 1/2 | 24,5 | 0,96 | 10 | 150 | 30 | 450 | 0,57 | 0,38 | 42 | 1,7 | 120 | 400 |
| 1423436 | 19 | 3/4 | 30,5 | 1,20 | 10 | 150 | 30 | 450 | 0,75 | 0,47 | 60 | 2,4 | 120 | 400 |
| 1423169 | 25 | 1 | 36,5 | 1,44 | 10 | 150 | 30 | 450 | 0,93 | 0,58 | 75 | 3,0 | 120 | 400 |
| 1423380 | 30 | 1-3/16 | 41,5 | 1,64 | 10 | 150 | 30 | 450 | 1,07 | 0,67 | 90 | 3,5 | 120 | 400 |
| 1423746 | 32 | 1-1/4 | 44 | 1,73 | 10 | 150 | 30 | 450 | 1,18 | 0,75 | 100 | 3,9 | 120 | 400 |
| 1422235 | 38 | 1-1/2 | 50 | 1,97 | 10 | 150 | 30 | 450 | 1,36 | 0,87 | 115 | 4,5 | 120 | 400 |
| 1423533 | 40 | 1-37/64 | 52 | 2,05 | 10 | 150 | 30 | 450 | 1,42 | 0,91 | 120 | 4,7 | 120 | 400 |
| 1427806 | 45 | 1-49/64 | 58 | 2,29 | 10 | 150 | 30 | 450 | 1,71 | 1,10 | 135 | 5,3 | 120 | 400 |
| 1422820 | 50 | 1-31/32 | 63 | 2,48 | 10 | 150 | 30 | 450 | 1,88 | 1,21 | 150 | 5,9 | 120 | 400 |
| 1423525 | 60 | 2-3/8 | 73,5 | 2,90 | 10 | 150 | 30 | 450 | 2,26 | 1,46 | 180 | 7,1 | 120 | 400 |
| 1448943 | 63,5 | 2 1/2 | 77 | 3,03 | 10 | 150 | 30 | 450 | 2,55 | 1,71 | 190 | 7,5 | 120 | 400 |
