Regulations
SAE J 2006.
/ Boat /
Navysil LO
High temperature air, water and wet exhaust suction and delivery hose
Highlights
Silicon solution
Suitable for high temperatures
Excellent bending radius
Application
hardwall, corrugated silicone hose used for the suction and delivery of fluids such as water mixed with anti-freeze liquids and hot air, with good resistance to mineral oils. Suitable to be used as a flexible connection in nautical engine cooling systems where a high temperature resistance is required.
Temperature
from -50°C to +180°C, peaks up to +200°C.
Construction
Tube: blue, smooth, silicone.
Reinforcement: synthetic cord plus steel helix wire.
Cover: blue, corrugated, silicone.
Reinforcement: synthetic cord plus steel helix wire.
Cover: blue, corrugated, silicone.
Branding: continuous red stripe “Boat (family logo) NAVYSIL LO - SAE J 2006 - W.P. 3 bar 45 psi S.F. 3:1 (IVG LOGO)”.
Available upon request
1.Different diameters.
2.Different colors.
3.Hardwall hose with smooth cover.
| Code | Inside diameter | Working pressure | Burst pressure | Weight nominal | Bending radius | Vacuum | Length max | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | bar | m | ft | |
| 1600705 | 19 | 3/4 | 3 | 45 | 9 | 135 | 0,5 | 0,34 | 70 | 2,8 | 0,9 | 60 | 200 |
| 1600706 | 25 | 1 | 3 | 45 | 9 | 135 | 0,67 | 0,44 | 90 | 3,5 | 0,9 | 60 | 200 |
| 1600707 | 32 | 1-1/4 | 3 | 45 | 9 | 135 | 0,81 | 0,54 | 110 | 4,3 | 0,9 | 60 | 200 |
| 1600708 | 38 | 1-1/2 | 3 | 45 | 9 | 135 | 1,02 | 0,69 | 130 | 5,1 | 0,9 | 60 | 200 |
| 1600213 | 51 | 2 | 3 | 45 | 9 | 135 | 1,31 | 0,88 | 200 | 7,9 | 0,9 | 60 | 200 |
| 1600709 | 63,5 | 2-1/2 | 3 | 45 | 9 | 135 | 1,59 | 1,07 | 300 | 11,8 | 0,9 | 60 | 200 |
| 1700042 | 76 | 3 | 3 | 45 | 9 | 135 | 1,99 | 1,34 | 350 | 13,8 | 0,9 | 60 | 200 |
| 1700583 | 90 | 3-35/64 | 3 | 45 | 9 | 135 | 2,33 | 1,56 | 450 | 17,7 | 0,9 | 60 | 200 |
| 1700584 | 102 | 4 | 3 | 45 | 9 | 135 | 2,61 | 1,75 | 500 | 19,7 | 0,9 | 12 | 40 |
| 1700586 | 127 | 5 | 1 | 15 | 3 | 45 | 4,01 | 2,70 | 640 | 25,2 | 0,9 | 12 | 40 |
| 1700587 | 152 | 6 | 1 | 15 | 3 | 45 | 4,74 | 3,19 | 800 | 31,5 | 0,9 | 12 | 40 |
| 1700589 | 203 | 8 | 1 | 15 | 3 | 45 | 7,58 | 5,09 | 1100 | 43,3 | 0,9 | 12 | 40 |
