Radiator hose DIN 73411-79
Highlights
Wide range of diameters
Safe and durable
Heat resistant
Application
softwall hose for conveying hot water mixed with anti-freeze liquids in cooling systems.
Temperature
from -40°C (-40°F) to +120°C (+248°F).
Construction
Tube: black, smooth, heat resistant synthetic rubber.
Reinforcement: high strength synthetic cord.
Cover: black, smooth (wrapped finish), heat and ageing resistant synthetic rubber.
Reinforcement: high strength synthetic cord.
Cover: black, smooth (wrapped finish), heat and ageing resistant synthetic rubber.
Branding: continuous marking in ink “IVG/DIN 73411-79/I.D./wall thickness/type of reinforcement/year/quarter”.
Available upon request
1.Different diameters.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Length max | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | m | ft | |
| 1237586 | 8 | 5/16 | 15 | 0,59 | 4 | 60 | 12 | 180 | 0,15 | 0,10 | 120 | 400 |
| 1336193 | 12 | 15/32 | 19 | 0,75 | 4 | 60 | 12 | 180 | 0,19 | 0,13 | 120 | 400 |
| 1240595 | 14 | 9/16 | 21 | 0,83 | 4 | 60 | 12 | 180 | 0,2 | 0,13 | 120 | 400 |
| 1160044 | 15 | 19/32 | 22 | 0,87 | 4 | 60 | 12 | 180 | 0,23 | 0,16 | 120 | 400 |
| 1160036 | 20 | 25/32 | 27 | 1,06 | 4 | 60 | 12 | 180 | 0,3 | 0,20 | 120 | 400 |
| 1160010 | 25 | 1 | 32 | 1,26 | 4 | 60 | 12 | 180 | 0,36 | 0,24 | 120 | 400 |
| 1159917 | 32 | 1-1/4 | 40 | 1,58 | 4 | 60 | 12 | 180 | 0,49 | 0,33 | 120 | 400 |
| 1159925 | 38 | 1-1/2 | 48 | 1,89 | 4 | 60 | 12 | 180 | 0,78 | 0,52 | 120 | 400 |
| 1220063 | 50 | 1-31/32 | 60 | 2,36 | 3 | 45 | 9 | 135 | 0,99 | 0,67 | 120 | 400 |
| 1159992 | 65 | 2-9/16 | 75 | 2,96 | 3 | 45 | 9 | 135 | 1,26 | 0,85 | 120 | 400 |
| 1160087 | 75 | 2-61/64 | 85 | 3,35 | 3 | 45 | 9 | 135 | 1,45 | 0,97 | 120 | 400 |
| 1226703 | 100 | 3-15/16 | 112,5 | 4,43 | 2 | 30 | 6 | 90 | 2,37 | 1,60 | 120 | 400 |
