Air brake DIN 74310
Extruded hose for brake systems
Highlights
Extruded hose
Resistance to abrasion and atmospheric agents
Easy to handle
Application
used as flexible joint in automotive air brake systems. Suitable for compressed air with oil traces.
Temperature
from -40°C (-40°F) to +70°C (+158°F).
Construction
Tube: black, seamless synthetic rubber compound.
Reinforcement: high strength synthetic fabrics.
Cover:
Reinforcement: high strength synthetic fabrics.
Cover:
black, seamless, synthetic rubber compound abrasion and weathering resistant.
Branding: IVG AIR BRAKE DIN 74310 – SIZE - QUARTER / YEAR - BATCH PRODUCTION NUMBER.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Bending radius | Length max | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | mm | inch | m | ft | |
| 1493493 | 9 | 23/64 | 16 | 0,63 | 10 | 150 | 25 | 375 | 0,21 | 0,14 | 60 | 2,4 | 80 | 262 |
| 1444816 | 11 | 13/30 | 18 | 0,71 | 10 | 150 | 25 | 375 | 0,25 | 0,13 | 70 | 2,8 | 80 | 262 |
| 1444824 | 13 | 1/2 | 25 | 0,99 | 10 | 150 | 25 | 375 | 0,54 | 0,32 | 100 | 3,9 | 50 | 164 |
