Alaska
Steel wire compressed air hose
Highlights
Robust construction
Anti-kinking structure
High working pressure
Application
high pressure steel wire reinforced compressed air hose; designed for applications where a heavy duty hose is necessary.
Temperature
from -30°C (-22°F) to +70°C (+158°F).
Construction
Tube: black, smooth, SBR rubber.
Reinforcement: inserts of steel wire.
Cover: yellow, smooth, (wrapped finish) long lasting EPDM rubber, weathering and ozone resistant.
Reinforcement: inserts of steel wire.
Cover: yellow, smooth, (wrapped finish) long lasting EPDM rubber, weathering and ozone resistant.
Branding: continuous blue stripe “IVG Air (Family Logo)...”.
Available upon request
1.Hose cover according to MSHA specification
2.Different diameters
3.Black cover
4.Different working pressures
5.Tube resistant to oil mist traces
6.Version resistant to temperatures up to 100°C.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Length max | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | m | ft | |
| 1282565 | 13 | 1/2 | 25,5 | 1,00 | 70 | 1050 | 210 | 3150 | 0,57 | 0,38 | 120 | 400 |
| 1282557 | 19 | 3/4 | 31,5 | 1,24 | 50 | 750 | 150 | 2250 | 0,75 | 0,50 | 120 | 400 |
| 1225740 | 25 | 1 | 37,5 | 1,48 | 45 | 675 | 135 | 2025 | 0,92 | 0,62 | 120 | 400 |
| 1290690 | 32 | 1-1/4 | 44,5 | 1,75 | 45 | 675 | 135 | 2025 | 1,22 | 0,82 | 120 | 400 |
| 1264176 | 38 | 1-1/2 | 51 | 2,01 | 45 | 675 | 135 | 2025 | 1,47 | 0,99 | 120 | 400 |
| 1359568 | 51 | 2 | 65 | 2,56 | 40 | 600 | 120 | 1800 | 1,98 | 1,33 | 120 | 400 |
| 1289012 | 63,5 | 2-1/2 | 80 | 3,15 | 35 | 525 | 105 | 1575 | 2,85 | 1,92 | 120 | 400 |
| 1359550 | 76 | 3 | 95 | 3,74 | 35 | 525 | 105 | 1575 | 4,37 | 2,94 | 120 | 400 |
| 1359541 | 102 | 4 | 121 | 4,77 | 30 | 450 | 90 | 1350 | 5,7 | 3,83 | 60 | 200 |
