Regulations
AS 2660 class B.
/ Air /
FRAS air water
Compressed air hose and water hose for mines
Highlights
Fire resistant and conductive
Length up to 120 m
Flexible for easy handling
Application
fire resistant and conductive softwall hose for compressed air and water, used in mines.
Temperature
from -15°C (+5°F) to +70°C (+158°F).
Construction
Tube: black, smooth, conductive NBR rubber, oil resistant.
Reinforcement: high strength synthetic cord.
Cover: black, smooth, (wrapped finish) in conductive CR rubber, fire, oil, and weathering resistant.
Reinforcement: high strength synthetic cord.
Cover: black, smooth, (wrapped finish) in conductive CR rubber, fire, oil, and weathering resistant.
Branding: continuous orange stripe “IVG / AS 2660 B W.P. 17,5 Bar AIR/WATER FRAS”.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Length max | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | m | ft | |
| 1335626 | 13 | 1/2 | 22 | 0,87 | 17,5 | 263 | 70 | 1050 | 0,29 | 0,20 | 120 | 400 |
| 1335618 | 25 | 1 | 36 | 1,42 | 17,5 | 263 | 70 | 1050 | 0,65 | 0,43 | 120 | 400 |
| 1356852 | 38 | 1-1/2 | 51 | 2,01 | 17,5 | 263 | 70 | 1050 | 1,03 | 0,69 | 120 | 400 |
| 1335600 | 51 | 2 | 65,5 | 2,58 | 17,5 | 263 | 70 | 1050 | 1,51 | 0,99 | 120 | 400 |
