Regulations
Abrasion loss of the tube according to ISO 4649: 70 +/- 5mm3.
/ Abr /
Niagara
Plaster hose
Highlights
Flexible and easy to handle
High abrasion resistance
Also available with colored cover
Application
softwall hose, used for the spraying of concrete, plaster, and gypsum.
Temperature
from -40°C (-40°F) to +70°C (+158°F).
Construction
Tube:
Reinforcement:
Cover:
black, smooth, antistatic SBR/NR rubber, abrasion resistant.
Reinforcement:
high strength synthetic cord.
Cover:
black, smooth (wrapped finish), antistatic SBR/NR rubber, abrasion resistant.
Branding:
continuous red stripe “IVG Abr (family logo)...”.
Available upon request
1.Different diameters.
2.Cover in different colours.
3.Different working pressures.
4.Niagara LL for suction and discharge.
| Code | Inside diameter | Outside diameter | Working pressure | Burst pressure | Weight nominal | Length max | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | inch | mm | inch | bar | psi | bar | psi | kg/m | lbs/ft | m | ft | |
| 1140183 | 19 | 3/4 | 31 | 1,22 | 40 | 600 | 120 | 1800 | 0,47 | 0,32 | 120 | 400 |
| 1435167 | 25 | 1 | 37 | 1,46 | 40 | 600 | 120 | 1800 | 0,6 | 0,40 | 120 | 400 |
| 1292153 | 32 | 1-1/4 | 44 | 1,73 | 40 | 600 | 120 | 1800 | 0,76 | 0,51 | 120 | 400 |
| 1434667 | 35 | 1-3/8 | 48 | 1,89 | 40 | 600 | 120 | 1800 | 0,9 | 0,60 | 120 | 400 |
| 1006860 | 38 | 1-1/2 | 54 | 2,13 | 40 | 600 | 120 | 1800 | 1,21 | 0,81 | 120 | 400 |
| 1379208 | 40 | 1-37/64 | 54 | 2,13 | 40 | 600 | 120 | 1800 | 1,04 | 0,70 | 120 | 400 |
| 1442791 | 51 | 2 | 67,5 | 2,66 | 40 | 600 | 120 | 1800 | 1,64 | 1,10 | 120 | 400 |
| 1365240 | 65 | 2-9/16 | 85 | 3,35 | 40 | 600 | 120 | 1800 | 2,48 | 1,67 | 120 | 400 |
| 1007173 | 76 | 3 | 98 | 3,86 | 40 | 600 | 120 | 1800 | 2,92 | 1,96 | 120 | 400 |
| 1007009 | 90 | 3-35/64 | 119,5 | 4,71 | 40 | 600 | 120 | 1800 | 4,86 | 3,27 | 120 | 400 |
| 1030922 | 100 | 3-15/16 | 128 | 5,04 | 40 | 600 | 120 | 1800 | 4,98 | 3,35 | 120 | 400 |
